Direct Operated Poppet Design
The VQD1151U-5L uses a direct operated poppet construction with no sliding seals, supporting stable response and suitability for vacuum applications.
SMC
SMC VQD1151U-5L Solenoid Valve 24VDC 5/2-Way
$53.25
Available
PRODUCT GALLERY
01 / 2
Product images for part identification
SMC
SMC VQD1151U-5L Solenoid Valve 24VDC 5/2-Way
PRODUCT PRICE
USD
$53.25
Available to order
Request a Quote
Need multiple units or help confirming a model?
Contact our team.
Free U.S. Shipping
Standard delivery
30-Day Returns
Subject to return policy
Bulk Purchase
Request volume quotes
Secure Checkout
Shopify-powered checkout
PRODUCT DOCUMENTATION
Product Information
Technical specifications, features, applications and purchasing information.
Technical Specifications
| Brand | SMC |
| Model Number | VQD1151U-5L |
| Product Category | Solenoid Valve |
| Product Family | VQD1000 Series |
| Valve Type | 4-Port, Direct Operated Poppet, Single Solenoid |
| Mounting | Base Mounted |
| Coil Voltage | 24 VDC |
| Operating Pressure Range | 0 to 0.7 MPa (Vacuum to Positive Pressure) |
| Port Size | M5 Thread |
| Effective Area | 1.5 mm² (Large Flow Type) |
| Electrical Entry | L-Type Plug Connector, with Lead Wire, Light and Surge Voltage Suppressor |
| Mass | Approx. 34 g |
Key Features
Vacuum to 0.7 MPa Range
Operating from 0 MPa (vacuum) up to 0.7 MPa, the valve can be used in both vacuum and positive pressure pneumatic circuits.
Large Flow Capacity
The U designation indicates a large flow version with an effective area of 1.5 mm² for applications requiring higher flow through an M5 port.
L-Type Plug with Surge Suppressor
The L-type plug connector includes a lead wire, indicator light, and surge voltage suppressor for simplified and protected electrical installation.
Compact and Lightweight
With a mass of approximately 34 g, the valve is suited to space-constrained and weight-sensitive pneumatic assemblies.
Applications
- Vacuum and positive pressure directional control
- Compact pneumatic actuator control
- Pick-and-place vacuum circuits
- Medical and analytical equipment pneumatics
- Semiconductor handling systems
- Packaging machinery valve banks
- General industrial automation with M5 piping
- Base-mounted manifold valve applications
Purchase Information
We support online purchase of the SMC VQD1151U-5L Solenoid Valve. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
Frequently Asked Questions
What is the SMC VQD1151U-5L? The VQD1151U-5L is a 4-port, direct operated poppet solenoid valve from the SMC VQD1000 series with a large flow capacity and base mount design.
What is the coil voltage? The coil is rated for 24 VDC.
What is the operating pressure range? The valve operates from 0 MPa (vacuum) to 0.7 MPa.
Can the VQD1151U-5L be used for vacuum applications? Yes. The direct operated poppet design is suitable for vacuum applications up to -101.2 kPa, in addition to positive pressure operation.
What is the port size? The valve uses M5 threaded ports.
What is the effective area? The U (large flow) version has an effective area of 1.5 mm².
What type of electrical connection is provided? The L suffix denotes an L-type plug connector with lead wire, indicator light, and surge voltage suppressor.
What is the mass of the valve? The valve weighs approximately 34 g.
What is the valve type? It is a 4-port, direct operated poppet valve with single solenoid actuation.
What should be checked before ordering? Confirm the required port size (M5), flow capacity (large flow, 1.5 mm²), operating pressure range, coil voltage (24 VDC), and electrical entry type (L-type plug with lead wire).
Need help confirming a model?
Send us your part number and technical requirements.
