4-Way, 3-Position Exhaust Center
Three-position exhaust center configuration allows controlled venting of both actuator ports in the center position.
SMC
SMC VH211-02 Solenoid Valve 24VDC 2/2-Way
$47.20
Available
PRODUCT GALLERY
01 / 2
Product images for part identification
SMC
SMC VH211-02 Solenoid Valve 24VDC 2/2-Way
PRODUCT PRICE
USD
$47.20
Available to order
Request a Quote
Need multiple units or help confirming a model?
Contact our team.
Free U.S. Shipping
Standard delivery
30-Day Returns
Subject to return policy
Bulk Purchase
Request volume quotes
Secure Checkout
Shopify-powered checkout
PRODUCT DOCUMENTATION
Product Information
Technical specifications, features, applications and purchasing information.
Technical Specifications
| Brand | SMC |
| Model Number | VH211-02 |
| Product Category | Manual Valve / Solenoid Valve |
| Series | VH2 |
| Valve Type | 4-Way, 3-Position Exhaust Center Manual Valve |
| Port Size | 1/4 (Rc 1/4) |
| Piping and Mounting | Side Ported, Panel Mount |
| Number of Positions | 3 Position Exhaust Center |
| Handle Type | Standard Handle |
| Operating Pressure Range | 0 to 1.0 MPa |
| Proof Pressure | 1.5 MPa |
| Operating Temperature | -5 to 60°C |
| Flow Coefficient (Cv) | 0.38 (P to A/B) |
Key Features
Panel-Mount, Side-Ported Design
Side-ported body with panel mounting enables secure installation on control panels and machine interfaces.
1/4 Rc Port Size
1/4 Rc threaded ports provide a standard connection size for pneumatic tubing and fittings.
0 to 1.0 MPa Pressure Range
Rated for operating pressures from 0 to 1.0 MPa, with a proof pressure of 1.5 MPa.
Standard Handle Actuation
Standard lever handle provides manual directional control for pneumatic circuits.
Applications
- Manual pneumatic directional control
- Panel-mounted valve stations
- Double-acting cylinder control with center exhaust
- Machine setup and maintenance functions
- Industrial automation manual override stations
- Pneumatic circuits requiring 4-way, 3-position control
Purchase Information
We support online purchase of the SMC VH211-02 Solenoid Valve. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
Frequently Asked Questions
What is the SMC VH211-02? The VH211-02 is a VH2 series 4-way, 3-position exhaust center manual valve with a 1/4 Rc port size, side-ported panel mounting, and standard handle.
What is the valve function? It is a 4-way, 3-position valve with exhaust center configuration.
What is the port size? The port size is 1/4 (Rc 1/4).
What is the operating pressure range? The operating pressure range is 0 to 1.0 MPa.
What is the proof pressure? The proof pressure is 1.5 MPa.
What is the operating temperature range? The operating temperature range is -5 to 60°C.
What is the Cv value of the VH211-02? The Cv value is 0.38 for flow from P to A/B.
How is the valve mounted? It is side-ported and designed for panel mounting.
What type of handle does it use? It uses a standard handle.
Is the VH211-02 a solenoid valve? The VH211-02 is a manual valve actuated by a handle; it does not use an electrical solenoid coil.
What should be verified before ordering? Confirm the complete model number, 4-way 3-position exhaust center function, 1/4 Rc port size, side-ported panel mounting, standard handle, 0 to 1.0 MPa pressure range, and operating temperature compatibility.
