DPDT Contact Configuration
Double-pole double-throw contacts provide two independent Form C changeover circuits in a single relay package.
1 / 1
Omron
Omron G5A-237P Relay 24VDC 5A SPDT
PRODUCT PRICE
USD
$14.13
0 pcs / pack
Available to order
Request a QuoteNeed multiple units or help confirming a model? Contact our team.
Payments
Available payment methods
Shop with confidence
30-Day Risk-Free Returns & Exchanges
Shop with complete confidence. Whatever the reason, enjoy hassle-free returns and exchanges within 30 days. We cover all shipping costs for both returns and exchanges—no extra shipping fees, no worries.
Service Guarantee
PRODUCT DOCUMENTATION
Product Information
Technical specifications, features, applications and purchasing information.
Technical Specifications
| Brand | Omron |
| Model Number | G5A-237P |
| Product Category | Relay |
| Coil Voltage | 24 VDC |
| Contact Configuration | DPDT (2 Form C) |
| Contact Current Rating | 1 A |
| Coil Resistance | 2.88 kΩ |
| Coil Current | 8.3 mA |
| Operate Time | 5 ms |
| Release Time | 5 ms |
| Operating Temperature | -40°C to 70°C |
| Mounting | Through Hole |
Key Features
24 VDC Coil
Standard 24 VDC coil voltage for use with common industrial control and signaling circuits.
Low Signal Switching
With a 1 A contact rating, the G5A-237P is suited for low-level signal switching and control applications.
Through-Hole Mounting
PC pin terminals support through-hole PCB assembly for reliable solder connections.
Compact DIP-8 Style Package
Compact package format allows dense placement on control boards and signal interface modules.
Applications
- Signal switching in control panels
- Telecommunication equipment
- Data acquisition systems
- Test and measurement instruments
- Industrial automation signal isolation
- PCB-mounted control circuits
- Security and alarm systems
Purchase Information
We support online purchase of the Omron G5A-237P Relay. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
Frequently Asked Questions
What is the Omron G5A-237P? The G5A-237P is a general-purpose relay with a 24 VDC coil and DPDT contacts, designed for PCB mounting.
What is the contact configuration? The contact configuration is DPDT (2 Form C).
What is the contact current rating? The contact current rating is 1 A.
What is the coil voltage and resistance? The coil is rated for 24 VDC with a resistance of 2.88 kΩ and a current of 8.3 mA.
What is the operating temperature range? The relay operates from -40°C to 70°C.
How is it mounted? The G5A-237P is designed for through-hole PCB mounting.
What should be checked before ordering? Confirm coil voltage, contact form, current rating, and PCB footprint.
