Five RJ45 Ports
The SCALANCE XB005 provides five electrical RJ45 Industrial Ethernet ports for connecting network devices in compact automation installations.
1 / 10
SIEMENS
SIEMENS 6GK5005-0BA00-1AB2 SCALANCE XB005 Ethernet Switch 5-Port 10/100Mbps
PRODUCT PRICE
USD
$67.68
0 pcs / pack
Available to order
Request a QuoteNeed multiple units or help confirming a model? Contact our team.
Payments
Available payment methods
Shop with confidence
30-Day Risk-Free Returns & Exchanges
Shop with complete confidence. Whatever the reason, enjoy hassle-free returns and exchanges within 30 days. We cover all shipping costs for both returns and exchanges—no extra shipping fees, no worries.
Service Guarantee
PRODUCT DOCUMENTATION
Product Information
Technical specifications, features, applications and purchasing information.
Technical Specifications
| Brand | SIEMENS |
| Model Number | 6GK5005-0BA00-1AB2 |
| Product Category | Industrial Ethernet Switch |
| Product Type | SCALANCE XB005 |
| Switch Type | Unmanaged Industrial Ethernet Switch |
| Electrical Ports | 5 x RJ45 |
| Transmission Rate | 10/100 Mbit/s |
| Network Topology | Small Star and Line Topologies |
| Auto Negotiation | Supported |
| Auto Crossover | Supported |
| Rated Supply Voltage | 24 VDC |
| Permissible Supply Voltage | 18-32 VDC |
| Power Loss | 2 W |
| Power Connection | 3-Pole Terminal Block |
| Diagnostic Indication | LED |
| Degree of Protection | IP20 |
| Mounting | 35 mm DIN Rail |
| Width | 40 mm |
| Height | 100 mm |
| Depth | 87 mm |
Key Features
10/100 Mbit/s Ethernet
Each electrical interface supports 10/100 Mbit/s transmission for applicable Industrial Ethernet communication networks.
Unmanaged Operation
The XB005 is an unmanaged switch intended for straightforward Ethernet connectivity without managed-switch configuration functions.
24 VDC Supply
The switch operates from a rated 24 VDC supply with a documented permissible voltage range of 18 to 32 VDC.
LED Diagnostics
Integrated LED indicators provide visual information for power and Ethernet port status during installation and operation.
Compact DIN Rail Design
The 40 mm wide enclosure is designed for mounting on a 35 mm DIN rail in applicable industrial control cabinets.
Applications
- Industrial Ethernet networks
- PLC and HMI network connections
- Machine automation systems
- Small star network topologies
- Industrial line network topologies
- Control cabinet Ethernet distribution
- Production equipment networking
- Factory automation communication
Purchase Information
We support online purchase of the SIEMENS 6GK5005-0BA00-1AB2 Industrial Ethernet Switch. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
Frequently Asked Questions
What is SIEMENS 6GK5005-0BA00-1AB2?
It is a SCALANCE XB005 unmanaged Industrial Ethernet switch for small industrial network installations.
How many Ethernet ports does the XB005 have?
It provides five electrical RJ45 Ethernet ports.
What transmission speeds are supported?
The electrical interfaces support 10 and 100 Mbit/s Ethernet transmission.
Is SCALANCE XB005 a managed switch?
No. The 6GK5005-0BA00-1AB2 is an unmanaged Industrial Ethernet switch.
What supply voltage does the switch use?
The rated supply voltage is 24 VDC.
What is the permissible input voltage range?
The documented permissible supply range is 18 to 32 VDC.
Does the switch support Auto Negotiation?
Yes. Auto Negotiation is supported on the Ethernet interfaces.
Does it support Auto Crossover?
Yes. Auto Crossover functionality is supported.
What network topologies can it be used for?
The XB005 is intended for small star and line Industrial Ethernet network topologies.
What is the protection rating?
The documented degree of protection is IP20.
How is the switch mounted?
It is designed for mounting on a 35 mm DIN rail in suitable industrial enclosures.
What should be checked before ordering?
Check the complete 6GK5005-0BA00-1AB2 article number together with the five RJ45 ports, 10/100 Mbit/s transmission, 24 VDC supply and unmanaged network requirements before ordering.
Need help confirming a model?
Send us your part number and technical requirements.
