1 NO + 1 NC Contacts
Provides one normally open and one normally closed contact with snap action for reliable position detection.
Schneider
Schneider XCKM102 Limit Switch 1NO 1NC 10A 500V
$23.98
Available
PRODUCT GALLERY
01 / 2
Product images for part identification
Schneider
Schneider XCKM102 Limit Switch 1NO 1NC 10A 500V
PRODUCT PRICE
USD
$23.98
Available to order
Request a Quote
Need multiple units or help confirming a model?
Contact our team.
Free U.S. Shipping
Standard delivery
30-Day Returns
Subject to return policy
Bulk Purchase
Request volume quotes
Secure Checkout
Shopify-powered checkout
PRODUCT DOCUMENTATION
Product Information
Technical specifications, features, applications and purchasing information.
Technical Specifications
| Brand | Schneider |
| Model Number | XCKM102 |
| Product Category | Limit Switch |
| Product Family | OsiSense XC Standard |
| Contact Configuration | 1 NC + 1 NO |
| Contact Operation | Snap Action |
| Rated Current | 10 A (thermal) |
| Rated Voltage | 500 V |
| Operator Type | Steel Roller Plunger |
| Body Material | Zamak (metal) |
| IP Degree of Protection | IP66 (EN/IEC 60529) |
| IK Degree of Protection | IK05 (EN 50102) |
| Operating Temperature | -25°C to +70°C |
| Mechanical Durability | 20,000,000 cycles |
| Electrical Durability | 5,000,000 cycles (DC-13) |
| Cable Entry | Pg11 |
Key Features
Steel Roller Plunger
Equipped with a steel roller plunger operator for mechanical actuation in industrial position sensing.
IP66 Protection
Rated IP66 for protection against dust and water jets, suitable for harsh industrial environments.
Zamak Metal Body
Housed in a robust Zamak metal body for mechanical durability in heavy-duty applications.
High Mechanical Durability
Rated for 20 million mechanical cycles and 5 million electrical cycles in DC-13 duty.
Applications
- Machine position detection
- Conveyor end-of-travel sensing
- Door and guard interlocking
- Valve and damper position feedback
- Packaging machinery indexing
- Elevator and lift position sensing
- Industrial automation end stops
Purchase Information
We support online purchase of the Schneider XCKM102 Limit Switch. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
Frequently Asked Questions
What is the Schneider XCKM102? The XCKM102 is a limit switch from the OsiSense XC Standard range with a steel roller plunger and 1 NO + 1 NC contacts.
What contact configuration does it have? It has one normally closed (NC) and one normally open (NO) contact with snap action.
What is the IP rating? The switch is rated IP66 conforming to EN/IEC 60529.
What is the operating temperature range? The operating ambient temperature range is -25°C to +70°C.
What is the mechanical durability? The mechanical durability is rated at 20,000,000 cycles.
What is the electrical durability? Electrical durability is rated at 5,000,000 cycles in DC-13 utilization category.
What type of operator does it use? It uses a steel roller plunger operator with spring return.
What is the cable entry type? The cable entry is Pg11.
What should be checked before ordering? Verify the contact configuration, actuation type, cable entry, IP rating, and mounting arrangement for your specific machine application.
