24VDC Control Coil
The documented control circuit voltage for RXM2AB2BD is 24 VDC.
Schneider RXM2AB2BD Miniature Plug-in Relay 24VDC 12A 2CO
Available in stock (200)
Regular price
$54.76
Sale price
Regular price
$0.00
Shipping calculated at checkout.
Technical Specifications
| Brand | Schneider |
| Model Number | RXM2AB2BD |
| Product Category | Miniature Plug-in Relay |
| Product Family | Harmony Electromechanical Relays |
| Relay Type | Miniature Relay |
| Contacts Type and Composition | 2 C/O |
| Control Circuit Voltage | 24 VDC |
| Conventional Enclosed Thermal Current | 12 A |
| Continuous Output Current | 10 A |
| Status LED | With |
| Control Type | Lockable Test Button |
| Average Coil Consumption | 0.9 W |
| Rated Insulation Voltage | 250 V |
| Rated Impulse Withstand Voltage | 4 kV |
| Operating Time | 20 ms |
| Maximum Switching Capacity | 3000 VA / 336 W |
| Operating Position | Any Position |
Key Features
2 C/O Contacts
The relay provides two changeover contacts for switching control circuits.
12A Thermal Current
Schneider specifies a conventional enclosed thermal current rating of 12 A.
Status LED
An integrated status LED provides visual indication of relay operating status.
Lockable Test Button
The documented configuration includes a lockable test button for relay actuation and checking.
0.9W Coil Consumption
Average coil consumption is specified at 0.9 W for the 24 VDC control configuration.
Applications
- Industrial control panel switching
- Machine control circuits
- PLC output interface circuits
- Automation relay control
- Electrical cabinet control circuits
- Signal switching applications
- Control circuit isolation functions
- Industrial equipment maintenance projects
Purchase Information
We support online purchase of the Schneider RXM2AB2BD Miniature Plug-in Relay. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
Frequently Asked Questions
What is Schneider RXM2AB2BD?
Schneider RXM2AB2BD is a miniature plug-in electromechanical relay with two changeover contacts, a 24 VDC control coil, status LED and lockable test button.
What control voltage does RXM2AB2BD use?
The documented control circuit voltage is 24 VDC.
How many contacts does RXM2AB2BD provide?
RXM2AB2BD provides two changeover contacts, specified as 2 C/O.
What is the thermal current rating of RXM2AB2BD?
Schneider specifies a conventional enclosed thermal current of 12 A.
What continuous output current is specified?
The documented continuous output current is 10 A.
Does RXM2AB2BD include an LED?
Yes. The relay configuration includes a status LED.
Does RXM2AB2BD have a test button?
Yes. Schneider specifies a lockable test button for this configuration.
What is the average coil consumption?
The documented average coil consumption is 0.9 W.
What is the operating time of RXM2AB2BD?
Schneider specifies an operating time of 20 ms.
What applications can RXM2AB2BD be considered for?
It can be considered for industrial control panels, machine control circuits, automation switching and other relay control applications after the electrical requirements have been checked.
What should be checked before ordering RXM2AB2BD?
Check the complete model number, 24 VDC control voltage, 2 C/O contact configuration, required current ratings, socket arrangement and electrical circuit requirements before purchasing.
