Door-Coupling Operation
The 3VL9300-3HF05 is a complete door-coupling rotary operating mechanism for operating suitable SENTRON 3VL molded case circuit breakers from the enclosure door.
SIEMENS 3VL9300-3HF05 Rotary Operating Mechanism IP65 300mm Shaft
Available in stock (400)
Regular price
$260.68
Sale price
Regular price
Shipping calculated at checkout.
Technical Specifications
| Brand | SIEMENS |
| Model Number | 3VL9300-3HF05 |
| Product Category | Rotary Operating Mechanism |
| Product Family | SENTRON 3VL |
| Product Designation | Door-Coupling Rotary Operating Mechanism |
| Installation | For Installation in Doors |
| Compatible Circuit Breakers | VL160X, VL160, VL250 / 3VL1 to 3VL3 |
| Degree of Protection | IP65 |
| Extension Shaft | 8 x 8 mm, 300 mm Length |
| Handle Color | Ti-Gray |
| Masking Plate | Light Gray |
| Locking | Lockable with Up to 3 Padlocks |
| Door Interlocking | Yes |
| Net Weight | 0.8 kg |
Key Features
IP65 Protection
The complete door-coupling rotary operating mechanism is specified with an IP65 degree of protection for suitable installations.
300 mm Extension Shaft
The assembly includes an 8 x 8 mm extension shaft with a documented length of 300 mm for coupling the door-mounted handle to the breaker mechanism.
Padlock Provision
The rotary operating mechanism can be locked with up to three padlocks as part of the documented mechanical operating arrangement.
Door Interlocking
The mechanism incorporates door interlocking for the applicable SENTRON 3VL circuit breaker installation.
VL160X to VL250 Application
The 3VL9300-3HF05 is specified for VL160X, VL160 and VL250 circuit breakers, corresponding to the 3VL1 through 3VL3 frame range.
Applications
- SENTRON 3VL circuit breaker installations
- Electrical distribution panels
- Industrial switchboards
- Machine control cabinets
- Molded case circuit breaker enclosures
- Industrial power distribution systems
- Door-mounted breaker operation
- Electrical equipment control panels
Purchase Information
We support online purchase of the SIEMENS 3VL9300-3HF05 Rotary Operating Mechanism. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
Frequently Asked Questions
What is SIEMENS 3VL9300-3HF05?
It is a SENTRON 3VL door-coupling rotary operating mechanism designed for installation in enclosure doors.
Which circuit breakers is 3VL9300-3HF05 designed for?
It is specified for VL160X, VL160 and VL250 circuit breakers, corresponding to the 3VL1 through 3VL3 range.
What is the degree of protection?
The complete door-coupling rotary operating mechanism is specified with an IP65 degree of protection.
What extension shaft is supplied with 3VL9300-3HF05?
The documented configuration includes an 8 x 8 mm extension shaft with a length of 300 mm.
What color is the operating handle?
The handle is Ti-gray and the masking plate is light gray.
Can the rotary operating mechanism be padlocked?
Yes. The documented mechanism is lockable with up to three padlocks.
Does 3VL9300-3HF05 include door interlocking?
Yes. Door interlocking is included in the documented configuration.
What is the net weight of 3VL9300-3HF05?
The documented net weight is approximately 0.8 kg.
Is 3VL9300-3HF05 installed directly on the enclosure door?
It is a door-coupling operating mechanism intended for installation in doors and covers, with the extension shaft coupling the handle assembly to the breaker operating mechanism.
Can 3VL9300-3HF05 be considered for another 3VL circuit breaker size?
It should only be considered after the exact circuit breaker frame and accessory requirements are checked. This article is specified for VL160X through VL250 / 3VL1 through 3VL3.
What should be checked before ordering?
Check the complete 3VL9300-3HF05 article number, circuit breaker frame, door installation arrangement, required shaft length and enclosure requirements before ordering.
