250 mm Axial Design
The A2E250-AP06-05 is a 250 mm AC axial fan with seven sickle-shaped blades and a single-intake configuration.
Ebmpapst A2E250-AP06-05 Axial Fan 230VAC 250mm 125/160W
Available in stock (200)
Regular price
$151.18
Sale price
Regular price
Shipping calculated at checkout.
Technical Specifications
| Brand | Ebmpapst |
| Model Number | A2E250-AP06-05 |
| Product Category | Axial Fan |
| Fan Type | AC Axial Fan, Sickle-Shaped Blades, Single-Intake |
| Motor Model | M2E068-CF |
| Fan Size | 250 mm |
| Phase | 1-Phase |
| Rated Voltage | 230 VAC |
| Frequency | 50/60 Hz |
| Power Input | 125 W at 50 Hz / 160 W at 60 Hz |
| Rated Current | 0.55 A at 50 Hz / 0.70 A at 60 Hz |
| Speed | 2350 RPM at 50 Hz / 2325 RPM at 60 Hz |
| Capacitor | 3 µF / 400 VDB |
| Max. Back Pressure | 125 Pa at 50 Hz / 120 Pa at 60 Hz |
| Number of Blades | 7 |
| Blade Material | Sheet Steel Blank with PP Plastic Coating |
| Degree of Protection | IP44, Installation- and Position-Dependent |
| Insulation Class | Class F |
| Bearing Type | Ball Bearing |
| Motor Protection | Thermal Overload Protector, Internally Connected |
| Airflow Direction | V |
| Direction of Rotation | Counterclockwise, Viewed Toward Rotor |
| Weight | 1.67 kg |
Key Features
230 VAC Operation
The fan uses a single-phase 230 VAC supply with documented operating ratings for both 50 Hz and 60 Hz.
125/160 W Power Input
Manufacturer data specifies 125 W power input at 50 Hz and 160 W at 60 Hz for the CE configuration.
2350/2325 RPM Speed
The documented rotational speed is 2350 RPM at 50 Hz and 2325 RPM at 60 Hz for the CE configuration.
IP44 Protection
The technical description specifies IP44 protection depending on installation and position, together with Class F insulation.
Ball Bearing Motor
The M2E068-CF motor uses ball bearings and an internally connected thermal overload protector.
Applications
- Industrial equipment cooling
- Electrical cabinet ventilation
- Control panel thermal management
- Power electronics cooling
- Refrigeration equipment ventilation
- HVAC equipment
- Industrial air circulation
- Axial fan system maintenance
Purchase Information
We support online purchase of the Ebmpapst A2E250-AP06-05 Axial Fan. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
Frequently Asked Questions
What is Ebmpapst A2E250-AP06-05?
It is a 250 mm single-phase AC axial fan with seven sickle-shaped blades and a single-intake configuration.
What voltage does A2E250-AP06-05 use?
The manufacturer datasheet specifies a nominal voltage of 230 VAC.
What frequency does A2E250-AP06-05 support?
Manufacturer nominal data provides ratings for both 50 Hz and 60 Hz.
What is the power input?
The CE nominal data specifies 125 W at 50 Hz and 160 W at 60 Hz.
What is the rated current?
The CE nominal data specifies 0.55 A at 50 Hz and 0.70 A at 60 Hz.
What is the fan speed?
The documented CE ratings are 2350 RPM at 50 Hz and 2325 RPM at 60 Hz.
What is the fan size?
The manufacturer technical description specifies a size of 250 mm.
What capacitor is specified?
The documented capacitor is 3 µF with a capacitor voltage of 400 VDB.
What is the protection rating?
The manufacturer specifies IP44 protection, dependent on installation and position, with Class F insulation.
What bearing type is used?
The motor uses ball bearings.
What motor is used?
The manufacturer datasheet identifies the motor as M2E068-CF.
What should be checked before ordering A2E250-AP06-05?
Check the complete model number, 230 VAC supply, 50/60 Hz frequency, 250 mm size, electrical ratings, capacitor, airflow direction and mounting requirements before purchasing.
