3-Phase AC Fan
The A2D200-AA02-33 is a 3-phase axial fan rated for 230 VAC (Δ) or 400 VAC (Y) operation.
1 / 1
Ebmpapst
Ebmpapst A2D200-AA02-33 Centrifugal Fan 400V 200mm
PRODUCT PRICE
USD
$497.98
0 pcs / pack
Available to order
Request a QuoteNeed multiple units or help confirming a model? Contact our team.
Payments
Available payment methods
Shop with confidence
30-Day Risk-Free Returns & Exchanges
Shop with complete confidence. Whatever the reason, enjoy hassle-free returns and exchanges within 30 days. We cover all shipping costs for both returns and exchanges—no extra shipping fees, no worries.
Service Guarantee
PRODUCT DOCUMENTATION
Product Information
Technical specifications, features, applications and purchasing information.
Technical Specifications
| Brand | Ebmpapst |
| Model Number | A2D200-AA02-33 |
| Product Category | Centrifugal Fan |
| Fan Type | Axial Fan, 3-Phase |
| Voltage | 230 VAC (Δ) / 400 VAC (Y) |
| Frequency | 50/60 Hz |
| Power | 53 W / 70 W |
| Current | 0.15 A / 0.14 A |
| Speed | 2800 RPM / 3150 RPM |
| Airflow | 524.2 CFM (14.68 m³/min) |
| Static Pressure | 140 Pa |
| Dimensions | 195 mm Dia. |
| Bearing Type | Ball |
| IP Rating | IP44 |
Key Features
2800/3150 RPM
Documented speed of 2800 RPM at 50 Hz or 3150 RPM at 60 Hz.
53 W / 70 W Power
Power rating is documented as 53 W or 70 W depending on operating frequency.
524.2 CFM Airflow
Delivers a documented airflow of 524.2 CFM (14.68 m³/min).
IP44 Protection
Rated IP44 for protection against limited dust ingress and water splashes.
Ball Bearing
Equipped with a ball bearing as documented in the specifications.
Applications
- Inverter cooling
- Industrial drive thermal management
- Control cabinet ventilation
- Power electronics cooling
- HVAC air movement
- 3-phase fan installations
- Equipment enclosure cooling
- Process air circulation
Purchase Information
We support online purchase of the Ebmpapst A2D200-AA02-33 Centrifugal Fan. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
Frequently Asked Questions
What is the Ebmpapst A2D200-AA02-33? It is a 3-phase axial fan rated for 230 VAC (Δ) or 400 VAC (Y) operation.
What is the voltage? The documented voltage is 230 VAC (Δ) or 400 VAC (Y).
What is the power rating? The power is documented as 53 W or 70 W.
What is the speed? The documented speed is 2800 RPM at 50 Hz or 3150 RPM at 60 Hz.
What is the airflow? The documented airflow is 524.2 CFM (14.68 m³/min).
What is the static pressure? The documented static pressure is 140 Pa.
What is the IP rating? The IP rating is IP44.
What bearing type is used? It uses a ball bearing.
Need help confirming a model?
Send us your part number and technical requirements.
