PROFIBUS OLM/G12 V4.0
Optical link module designed for PROFIBUS networks, supporting standard transmission distances up to 2850 m.
SIEMENS
SIEMENS 6GK1503-3CB00 PLC Module PROFIBUS Optical Link Module
$580.20
Available
PRODUCT GALLERY
01 / 5
Product images for part identification
SIEMENS
SIEMENS 6GK1503-3CB00 PLC Module PROFIBUS Optical Link Module
PRODUCT PRICE
USD
$580.20
Available to order
Request a Quote
Need multiple units or help confirming a model?
Contact our team.
Free U.S. Shipping
Standard delivery
30-Day Returns
Subject to return policy
Bulk Purchase
Request volume quotes
Secure Checkout
Shopify-powered checkout
PRODUCT DOCUMENTATION
Product Information
Technical specifications, features, applications and purchasing information.
Technical Specifications
| Brand | SIEMENS |
| Model Number | 6GK1503-3CB00 |
| Product Category | PLC Module |
| Product Type | PROFIBUS OLM/G12 V4.0 Optical Link Module |
| Transmission Rate | 9.6 kbit/s to 12 Mbit/s |
| PROFIBUS PA Rate | 45.45 kbit/s |
| Electrical Interface | 1 x RS 485 (9-pin Sub-D socket) |
| Optical Interfaces | 2 x glass FOC (4 BFOC sockets) |
| Maximum Distance | 2850 m |
| Signaling Contact | 24 V DC, 0.1 A |
| Supply Voltage | 24 V DC (18.8 to 28.8 V) |
| Current Consumption | 0.2 A at 24 V DC |
| Operating Temperature | 0°C to +60°C |
| Protection Rating | IP40 |
| Dimensions (W x H x D) | 39.5 mm x 112 mm x 74.5 mm |
| Mounting | 35 mm DIN-rail / Wall mounting |
Key Features
RS 485 and Glass FOC Interfaces
Equipped with one RS 485 electrical interface and two glass fiber optic interfaces with BFOC sockets for flexible network integration.
Automatic Data Rate Detection
Detects all PROFIBUS data rates from 9.6 kbit/s up to 12 Mbit/s automatically, including 45.45 kbit/s for PROFIBUS PA.
Signaling Contact and Measuring Output
Includes a signaling contact and measuring output for network diagnostics and monitoring.
DIN-Rail and Wall Mounting
Supports 35 mm DIN-rail mounting as well as wall mounting for installation flexibility.
Applications
- PROFIBUS network segment extension
- Optical fiber transmission in industrial environments
- Long-distance PROFIBUS communication
- Network diagnostics and monitoring
- Industrial automation network infrastructure
- PROFIBUS PA system integration
Purchase Information
We support online purchase of the SIEMENS 6GK1503-3CB00 PLC Module. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
Frequently Asked Questions
What is the SIEMENS 6GK1503-3CB00? The 6GK1503-3CB00 is a PROFIBUS OLM/G12 V4.0 Optical Link Module from Siemens.
What interfaces does the 6GK1503-3CB00 provide? It provides 1 RS 485 electrical interface and 2 glass FOC interfaces (4 BFOC sockets).
What is the maximum transmission distance? The module supports standard distances up to 2850 m with glass fiber optic cable.
What data rates are supported? It supports PROFIBUS data rates from 9.6 kbit/s to 12 Mbit/s, including 45.45 kbit/s for PROFIBUS PA.
What is the supply voltage requirement? The module requires a 24 V DC supply voltage (18.8 to 28.8 V).
What is the operating temperature range? The operating temperature range is 0°C to +60°C.
What is the protection rating? The module has an IP40 protection rating.
How is the module mounted? It supports 35 mm DIN-rail mounting and wall mounting.
Need help confirming a model?
Send us your part number and technical requirements.
