4 RTD/TC Analog Inputs
The module provides four analog inputs for resistance temperature detectors and thermocouples in ET 200SP systems.
1 / 2
SIEMENS
SIEMENS 6ES7134-6JD00-0CA1 Input Module 4 Analog Inputs 4-20mA
PRODUCT PRICE
USD
$120.46
Available to order
Request a QuoteNeed multiple units or help confirming a model? Contact our team.
Payments
Available payment methods
Shop with confidence
Bulk orders & part matching
Contact our team for quantity requests and help confirming your part number.
Service Guarantee
PRODUCT DOCUMENTATION
Product Information
Technical specifications, features, applications and purchasing information.
Technical Specifications
| Brand | SIEMENS |
| Model Number | 6ES7134-6JD00-0CA1 |
| Product Category | Analog Input Module |
| Product Family | SIMATIC ET 200SP |
| Module Type | AI 4xRTD/TC High Feature |
| Number of Analog Inputs | 4 |
| Input Types | RTD and Thermocouple |
| Resolution | 16 bit |
| Accuracy | +/-0.1% |
| Connection Method | 2-wire, 3-wire, 4-wire |
| Supply Voltage | 24 VDC |
| Permissible Voltage Range | 19.2 VDC to 28.8 VDC |
| Power Loss | 0.75 W (typical) |
| Channel Diagnostics | Yes |
| Compatible BaseUnits | BU type A0, A1 |
| Color Code | CC00 |
Key Features
16-Bit Resolution
Each input channel offers 16-bit resolution for precise temperature and analog signal acquisition.
2/3/4-Wire Connection
Inputs support 2-wire, 3-wire, and 4-wire connection methods for flexible sensor wiring.
Channel Diagnostics
The module includes channel diagnostics for fault detection in temperature measurement applications.
High Feature Version
As an AI 4xRTD/TC High Feature module, it is designed for demanding temperature measurement tasks in ET 200SP.
BU Type A0/A1 Compatibility
The module fits BU type A0 and A1 base units and uses CC00 color coding.
Applications
- Temperature measurement with RTD sensors
- Thermocouple-based process temperature monitoring
- SIMATIC ET 200SP analog input expansion
- Industrial furnace and oven temperature control
- HVAC and building automation temperature acquisition
- Process industry temperature monitoring
- Machine thermal monitoring
- Control cabinet analog signal integration
Purchase Information
We support online purchase of the SIEMENS 6ES7134-6JD00-0CA1 Analog Input Module. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
Frequently Asked Questions
What is the SIEMENS 6ES7134-6JD00-0CA1? The 6ES7134-6JD00-0CA1 is a SIMATIC ET 200SP AI 4xRTD/TC High Feature analog input module.
How many analog inputs does this module have? It provides four analog inputs for RTD and thermocouple sensors.
What is the resolution of the analog inputs? The resolution is 16 bit.
What is the accuracy specification? The accuracy is +/-0.1%.
What connection methods are supported? The module supports 2-wire, 3-wire, and 4-wire sensor connection.
What supply voltage does the module require? The rated supply voltage is 24 VDC, with a permissible range of 19.2 VDC to 28.8 VDC.
Does the module provide channel diagnostics? Yes, channel diagnostics are supported.
Which BaseUnit types are compatible? The module is compatible with BU type A0 and A1 base units.
What is the typical power loss? The typical power loss is 0.75 W.
