2 PT100/PT1000 Inputs
The module provides two analog inputs for PT100 or PT1000 resistance thermometers, with mixed sensor types permissible.
SIEMENS
SIEMENS 6ED1055-1MD00-0BA2 Input Module 4 Analog Inputs 0-10V
$112.31
Available
PRODUCT GALLERY
01 / 2
Product images for part identification
SIEMENS
SIEMENS 6ED1055-1MD00-0BA2 Input Module 4 Analog Inputs 0-10V
PRODUCT PRICE
USD
$112.31
Available to order
Request a Quote
Need multiple units or help confirming a model?
Contact our team.
Free U.S. Shipping
Standard delivery
30-Day Returns
Subject to return policy
Bulk Purchase
Request volume quotes
Secure Checkout
Shopify-powered checkout
PRODUCT DOCUMENTATION
Product Information
Technical specifications, features, applications and purchasing information.
Technical Specifications
| Brand | SIEMENS |
| Model Number | 6ED1055-1MD00-0BA2 |
| Product Category | Analog Input Module |
| Product Family | LOGO! 8 |
| Module Type | AM2 RTD Expansion Module |
| Number of Analog Inputs | 2 |
| Input Type | PT100 / PT1000 Resistance Thermometer |
| Sensor Connection | 2-wire or 3-wire |
| Supply Voltage | 12/24 VDC |
| Permissible Voltage Range | 10.8 VDC to 28.8 VDC |
| Digital Input Resolution | 10-bit |
| Protection Rating | IP20 |
| Operating Temperature | 0°C to +55°C |
| Dimensions (W x H x D) | 35.5 x 90 x 58 mm |
| Mounting | 35 mm DIN rail, 2 spacing units wide |
Key Features
2-Wire and 3-Wire Connection
Each input supports 2-wire or 3-wire sensor connection for flexible temperature measurement wiring.
12/24 VDC Supply
The expansion module operates on 12 VDC or 24 VDC, with a permissible range of 10.8 VDC to 28.8 VDC.
LOGO! 8 Integration
As a LOGO! AM2 RTD expansion module, it extends the analog temperature input capability of LOGO! 8 logic modules.
DIN Rail Mounting
The module mounts on 35 mm DIN rail and occupies 2 spacing units for compact control cabinet installation.
10-Bit Resolution
The digital input resolution is specified as 10-bit for temperature signal acquisition.
Applications
- Temperature measurement with PT100 or PT1000 sensors
- LOGO! 8 logic module analog input expansion
- HVAC temperature monitoring and control
- Building automation sensor interfacing
- Industrial process temperature acquisition
- Machine temperature monitoring
- Small-scale automation panel integration
- Retrofit temperature input expansion
Purchase Information
We support online purchase of the SIEMENS 6ED1055-1MD00-0BA2 Analog Input Module. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
Frequently Asked Questions
What is the SIEMENS 6ED1055-1MD00-0BA2? The 6ED1055-1MD00-0BA2 is a LOGO! AM2 RTD expansion module with two analog inputs for PT100 or PT1000 sensors.
How many analog inputs does this module have? It provides two analog inputs.
What sensor types are supported? The module supports PT100 and PT1000 resistance thermometers, and mixing the sensor types is permissible.
What supply voltage does the module require? The rated supply voltage is 12/24 VDC, with a permissible range of 10.8 VDC to 28.8 VDC.
Does the module support 3-wire sensor connection? Yes, each analog input supports 2-wire or 3-wire connection.
What is the protection rating? The module has an IP20 protection rating.
What is the operating temperature range? The operating temperature range is 0°C to +55°C.
How is the module mounted? It mounts on 35 mm DIN rail and is 2 spacing units wide.
What is the digital input resolution? The digital input resolution is 10-bit.
