Mersen FR10AM69V Fuse

PRODUCT PRICE USD

$35.42

Available to order

Request a Quote

Need multiple units or help confirming a model? Contact our team.

Payments

Available payment methods

Bank transfer

Shop with confidence

30-Day Risk-Free Returns & Exchanges

Shop with complete confidence. Whatever the reason, enjoy hassle-free returns and exchanges within 30 days. We cover all shipping costs for both returns and exchanges—no extra shipping fees, no worries.

View Our Return Policy

Service Guarantee

Shipping

Free standard shipping within the U.S

Shipping details

Estimated delivery

Expected to arrive within 2–15 days

Delivery details

Enjoy greater discounts on bulk orders

Please contact our team for bulk purchases

Contact our team

PRODUCT DOCUMENTATION

Product Information

Technical specifications, features, applications and purchasing information.

Technical Specifications

Brand	Mersen
Model Number	FR10AM69V
Product Category	Fuse
Fuse Type	Cylindrical Cartridge Fuse
Utilization Category	aM (Partial-Range Motor Protection)
Rated Voltage AC	690 V
Fuse Size	10 x 38 mm
Breaking Capacity	120 kA
Body Material	Ceramic
Contact Material	Silver Plated
Mounting	Clip-On
Compliances	RoHS Compliant

Key Features

aM Motor Protection Characteristic

The aM partial-range characteristic is intended for motor circuit protection, coordinating with motor starters and overload relays.

10 x 38 mm Cylindrical Size

Compact 10 x 38 mm cylindrical fuse format for use in compatible clip-on fuse holders and modular fuse systems.

690 V AC Rating

Rated for 690 V AC applications, suitable for industrial motor circuits operating at higher voltages.

120 kA Breaking Capacity

A 120 kA breaking capacity provides high short-circuit current interruption capability for motor protection.

Ceramic Body with Silver-Plated Contacts

Ceramic fuse body and silver-plated copper contacts support stable electrical performance in industrial environments.

Applications

Motor circuit protection
Motor starter coordination
Industrial control panel fuse protection
Pump and fan motor circuits
Compressor motor protection
Machinery and OEM equipment

Purchase Information

We support online purchase of the Mersen FR10AM69V Fuse. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.

Frequently Asked Questions

What is the Mersen FR10AM69V? It is a Mersen cylindrical cartridge fuse in the 10 x 38 mm size, with an aM utilization category and a 690 V AC rating, designed primarily for motor circuit protection.

What is the utilization category? It is classified as aM for partial-range motor protection.

What is the voltage rating? The rated voltage is 690 V AC.

What is the physical size? The fuse is 10 x 38 mm.

What is the breaking capacity? The breaking capacity is 120 kA.

What body and contact materials are used? The fuse has a ceramic body with silver-plated contacts.

How is it mounted? It is designed for clip-on mounting in compatible fuse holders.

What applications is it intended for? It is primarily used for motor circuit protection, including pumps, fans, compressors, and other industrial motor loads.
