EC Motor Technology
Electronically commutated (EC) motor with a 380–480 VAC nominal voltage range for efficient variable-speed operation.
1 / 1
Ebmpapst
Ebmpapst R3G630-AB06-03 Centrifugal Fan 400VAC 630mm 1.5kW
PRODUCT PRICE
USD
$2,895.02
0 pcs / pack
Available to order
Request a QuoteNeed multiple units or help confirming a model? Contact our team.
Payments
Available payment methods
Shop with confidence
30-Day Risk-Free Returns & Exchanges
Shop with complete confidence. Whatever the reason, enjoy hassle-free returns and exchanges within 30 days. We cover all shipping costs for both returns and exchanges—no extra shipping fees, no worries.
Service Guarantee
PRODUCT DOCUMENTATION
Product Information
Technical specifications, features, applications and purchasing information.
Technical Specifications
| Brand | Ebmpapst |
| Model Number | R3G630-AB06-03 |
| Product Category | Centrifugal Fan |
| Fan Type | EC Centrifugal Fan, Backward Curved |
| Nominal Voltage Range | 380–480 VAC |
| Power Input | 2.8 kW |
| Speed | 1200 rpm |
| Air Flow | 10005 m³/h |
| Back Pressure | 555 Pa |
| Impeller Diameter | 630 mm |
| Depth | 306 mm |
| Bearing Type | Ball Bearing |
| Protection Rating | IP55 |
| Noise Level | 91 dBA |
| Housing Material | Die-cast Aluminium |
| Termination | Wire Leads |
Key Features
630mm Backward Curved Impeller
Large 630mm diameter backward-curved impeller for high-volume centrifugal air movement.
10005 m³/h Air Flow
Documented air flow of 10005 m³/h with 555 Pa back pressure for demanding ventilation and cooling duties.
IP55 Protection
IP55 protection rating for resistance to dust and water jets in industrial environments.
2.8kW Power Input
High-power EC motor rated at 2.8kW for large air handling and process cooling applications.
Applications
- Large air handling units
- Industrial ventilation systems
- Data center cooling
- Process cooling and exhaust
- Cleanroom air circulation
- HVAC plenum and duct fan sections
- High-volume commercial ventilation
Purchase Information
We support online purchase of the Ebmpapst R3G630-AB06-03 Centrifugal Fan. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
Frequently Asked Questions
What is the Ebmpapst R3G630-AB06-03? It is a 380–480 VAC EC centrifugal fan with a 630mm backward-curved impeller, 2.8kW power input, and 10005 m³/h air flow.
What is the air flow of the R3G630-AB06-03? The documented air flow is 10005 m³/h.
What is the back pressure? The documented back pressure is 555 Pa.
What is the speed? The documented speed is 1200 rpm.
What is the power input? The power input is 2.8 kW.
What is the protection rating? The protection rating is IP55.
What is the impeller diameter? The impeller diameter is 630 mm with a 306 mm depth.
What is the noise level? The documented noise level is 91 dBA.
Is the R3G630-AB06-03 an EC fan? Yes, it uses an EC (electronically commutated) motor with a 380–480 VAC voltage range.
