3 A Current Rating
The CCMR-3 corresponds to the documented CCMR 3 A rating, catalog number CCMR003.
Littelfuse CCMR-3 Time-Delay Fuse 3A 600VAC 300VDC Class CC
Available in stock (2000)
Regular price
$6.19
Sale price
Regular price
Shipping calculated at checkout.
Technical Specifications
| Brand | Littelfuse |
| Model Number | CCMR-3 |
| Product Category | Time-Delay Fuse |
| Series | CCMR |
| Fuse Class | Class CC |
| Fuse Type | Dual-Element Time-Delay |
| Current Rating | 3 A |
| AC Voltage Rating | 600 VAC |
| DC Voltage Rating | 300 VDC |
| AC Interrupting Rating | 200 kA RMS Symmetrical |
| DC Interrupting Rating | 20 kA |
| Catalog Number | CCMR003 |
| Product Marking | CCMR 3A |
| Approvals | UL Listed, CSA Certified |
| Compliance | RoHS Compliant |
Key Features
600 VAC Class CC Fuse
The 3 A CCMR fuse is within the Class CC range and is rated for AC circuits up to 600 VAC.
300 VDC Rating
The 3 A rating is within the CCMR range specified for operation up to 300 VDC.
Dual-Element Time-Delay
The CCMR series uses dual-element time-delay construction designed for motor and motor branch circuit protection.
200 kA AC Interrupting Rating
The documented AC interrupting rating is 200 kA RMS symmetrical, with a 20 kA DC interrupting rating.
UL and CSA Approvals
The applicable CCMR Class CC range is UL Listed and CSA Certified, with RoHS compliance documented for the 2.5 A through 30 A range.
Applications
- Motor branch circuit protection
- Small motor circuit protection
- Industrial control circuits
- Motor control panels
- Contactor protection
- Heating circuits
- Industrial electrical panels
- General industrial circuit protection
Purchase Information
We support online purchase of the Littelfuse CCMR-3 Time-Delay Fuse. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
Frequently Asked Questions
What is Littelfuse CCMR-3?
Littelfuse CCMR-3 is a CCMR series Class CC dual-element time-delay fuse with a 3 A current rating.
What is the current rating of CCMR-3?
The documented current rating is 3 A.
What is the AC voltage rating?
The CCMR-3 is rated for operation up to 600 VAC.
What is the DC voltage rating?
The 3 A CCMR rating is specified for operation up to 300 VDC.
Is CCMR-3 a time-delay fuse?
Yes. The CCMR series uses dual-element time-delay construction for motor and motor branch circuit protection.
What fuse class is CCMR-3?
The 3 A CCMR rating is a UL Class CC fuse.
What is the AC interrupting rating?
The documented AC interrupting rating is 200 kA RMS symmetrical.
What is the DC interrupting rating?
The documented DC interrupting rating is 20 kA.
What is the Littelfuse catalog number for the 3 A CCMR fuse?
Littelfuse lists CCMR003 as the catalog number and CCMR 3A as the product marking.
What applications is the CCMR series intended for?
The CCMR series is specified for motor and motor branch circuit protection and is also documented for contactor, heating and general industrial protection.
What approvals apply to the CCMR-3 rating?
The applicable CCMR Class CC range is UL Listed and CSA Certified, and the 3 A rating is within the RoHS-compliant 2.5 A through 30 A range.
What should be checked before ordering CCMR-3?
Check the complete CCMR-3 model designation, 3 A current rating, required 600 VAC or 300 VDC circuit rating, Class CC requirements, interrupting rating and fuseholder specifications before purchasing.
