R1/4 Male Thread
The QSW-1/4-8 provides an R1/4 male threaded connection for installation on compatible pneumatic components and compressed-air ports.
FESTO QSW-1/4-8 Push-In L-Fitting R1/4 8mm Pneumatic Connector
Available in stock (400)
Regular price
$22.08
Sale price
Regular price
Shipping calculated at checkout.
Technical Specifications
| Brand | Festo |
| Model Number | QSW-1/4-8 |
| Product Category | Push-In L-Fitting |
| Pneumatic Connection 1 | R1/4 Male Thread |
| Pneumatic Connection 2 | For 8 mm OD Tubing |
| Tube Outside Diameter | 8 mm |
| Design | 90° Push-In L-Fitting |
| Operating Pressure | -0.95 to 6 bar |
| Ambient Temperature | -10°C to +80°C |
| Operating Medium | Compressed Air |
| Housing Material | PBT |
| Threaded Connection Material | Nickel-Plated Brass |
Key Features
8 mm Push-In Connection
The push-in connection is designed for compatible pneumatic tubing with an 8 mm outside diameter, allowing a tube-to-thread pneumatic connection.
90° L-Shaped Design
The angled fitting configuration changes the tubing direction by 90 degrees, supporting pneumatic installations where tubing routing or available installation space is a consideration.
-0.95 to 6 bar Pressure Range
The specified operating pressure range is -0.95 to 6 bar, providing an important compatibility reference for pneumatic system selection.
-10°C to +80°C Temperature Range
The specified ambient temperature range supports use in compatible industrial pneumatic operating environments.
PBT and Nickel-Plated Brass
The fitting combines a PBT housing with a nickel-plated brass threaded connection for compatible pneumatic installations.
Applications
- Pneumatic tubing connections
- 90-degree tubing routing
- Solenoid valve connections
- Pneumatic cylinder circuits
- Compressed-air distribution
- Industrial machine automation
- Pneumatic control systems
- Equipment maintenance
Purchase Information
We support online purchase of the Festo QSW-1/4-8 Push-In L-Fitting. For bulk purchasing or additional product requirements, contact our team with the complete model number and required quantity. We can provide quantity quotations, estimated delivery information and available transportation options.
Frequently Asked Questions
What is Festo QSW-1/4-8?
It is a 90-degree pneumatic push-in fitting designed to connect compatible 8 mm OD tubing to an R1/4 male threaded pneumatic port.
What threaded connection does QSW-1/4-8 use?
The threaded pneumatic connection is R1/4 male.
What tube size does QSW-1/4-8 accept?
The push-in connection is designed for compatible pneumatic tubing with an 8 mm outside diameter.
Is QSW-1/4-8 a straight fitting?
No. It uses a 90-degree L-shaped configuration for angled pneumatic tubing connections.
What is the operating pressure range?
The specified operating pressure range is -0.95 to 6 bar.
What is the ambient temperature range?
The specified ambient temperature range is -10°C to +80°C.
What materials are used?
The fitting uses a PBT housing with a nickel-plated brass threaded connection.
What operating medium is specified?
The fitting is intended for compatible compressed-air pneumatic applications.
Where can QSW-1/4-8 be used?
Typical applications include pneumatic tubing connections, valves, cylinders, machine automation and installations requiring 90-degree tubing routing.
What should be checked before ordering?
Verify the complete QSW-1/4-8 model number, R1/4 male thread, 8 mm tube outside diameter, 90-degree fitting configuration and required pneumatic operating conditions before ordering.
