Eaton Bussmann

Bussmann 170M1512 Fuse

PRODUCT PRICE USD

$150.00

Available to order

Request a Quote

Need multiple units or help confirming a model? Contact our team.

Payments

Available payment methods

Bank transfer

Shop with confidence

30-Day Risk-Free Returns & Exchanges

Shop with complete confidence. Whatever the reason, enjoy hassle-free returns and exchanges within 30 days. We cover all shipping costs for both returns and exchanges—no extra shipping fees, no worries.

View Our Return Policy

Service Guarantee

Shipping

Free standard shipping within the U.S

Shipping details

Estimated delivery

Expected to arrive within 2–15 days

Delivery details

Enjoy greater discounts on bulk orders

Please contact our team for bulk purchases

Contact our team

PRODUCT DOCUMENTATION

Product Information

Technical specifications, features, applications and purchasing information.

Technical Specifications

Brand	Bussmann
Model Number	170M1512
Product Category	High-Speed Square Body Fuse
Product Series	170M
Fuse Type	DIN 43653 Square Body (French Style)
Voltage Rating	690 VAC (IEC) / 700 VAC (UL)
Amperage Rating	500 A
Interrupting Rating	200 kAIC
Operating Class	aR
Fuse Size	DIN 000 / 1*
Mounting Type	Bolt Down
Application	Semiconductor, DC Common Bus, DC Drives, Power Converters/Rectifiers

Key Features

High-Speed French Style Fuse

Square body French style fuse for fast semiconductor protection.

200 kAIC Interrupting Rating

High fault current capacity for industrial power systems.

aR Class

Semiconductor protection class for rectifier and converter circuits.

DIN 43653 Square Body

Standard square body dimensions with bolt-down mounting.

690 VAC / 700 VAC

Dual-rated for IEC and UL applications.

DC Bus and Drive Protection

Suitable for DC common bus, DC drives, power converters, and reduced voltage starters.

Applications

Semiconductor protection in DC drive systems
DC common bus fusing
Rectifier protection
Power converters
Reduced voltage starters
Industrial power supplies
UPS and DC distribution
DC motor control

Purchase Information

We support online purchase of the Bussmann 170M1512 High-Speed Square Body Fuse. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.

Frequently Asked Questions

What is the Bussmann 170M1512? A French style high-speed square body fuse from the 170M series.

What voltage does it support? 690 VAC (IEC) and 700 VAC (UL).

What is the amperage rating of the 170M1512? The catalog number is specified at 500 A.

What is the interrupting rating? 200 kAIC.

What is the operating class? Class aR.

What fuse size is used? DIN 000 French style square body.

How is it mounted? Bolt-down mounting.

What are common applications? DC drives, rectifiers, power converters, and common bus protection.

Is it designed for semiconductor protection? Yes, it is an aR semiconductor fuse.

What should be verified before purchase? Check voltage, continuous current, fault level, fuse size, and mounting arrangement.
