Eaton Bussmann

Bussmann 170M1316 Fuse

PRODUCT PRICE USD

$42.88

Available to order

Request a Quote

Need multiple units or help confirming a model? Contact our team.

Payments

Available payment methods

Bank transfer

Shop with confidence

30-Day Risk-Free Returns & Exchanges

Shop with complete confidence. Whatever the reason, enjoy hassle-free returns and exchanges within 30 days. We cover all shipping costs for both returns and exchanges—no extra shipping fees, no worries.

View Our Return Policy

Service Guarantee

Shipping

Free standard shipping within the U.S

Shipping details

Estimated delivery

Expected to arrive within 2–15 days

Delivery details

Enjoy greater discounts on bulk orders

Please contact our team for bulk purchases

Contact our team

PRODUCT DOCUMENTATION

Product Information

Technical specifications, features, applications and purchasing information.

Technical Specifications

Brand	Bussmann
Model Number	170M1316
Product Category	High Speed Square Body Fuse
Product Family	170M Series
Amperage Rating	80 A
Voltage Rating	690 V (IEC) / 700 V (UL)
Voltage Type	AC
Breaking Capacity	200 kA
Class	aR
Fuse Size	000
Clearing I²t at 660 V	2550 A²s
Pre-arc I²t	380 A²s
Watt Losses	19 W
Fuse Type	DIN 43653 U/80, without indicator, bolted tag
Mounting	Bolted tag
Product Length/Depth	105 mm
Product Height	46 mm
Product Weight	130 g

Key Features

High Speed aR Class

aR class fuse optimized for short-circuit protection of semiconductors with fast acting characteristics.

80 A Current Rating

Rated 80 A at 690 V AC (IEC) and 700 V AC (UL) for industrial power circuits.

200 kA Interrupting Rating

High breaking capacity of 200 kA supports robust fault current protection.

Square Body Construction

DIN 43653 U/80 square body with bolted tag terminals for secure mounting.

Semiconductor Protection

Designed for protection of power semiconductors, DC drives, and rectifiers.

Compact Size 000

Size 000 dimensions allow installation in space-constrained enclosures.

Applications

Semiconductor protection
DC common bus
DC drives
Power converters and rectifiers
Variable frequency drives
Industrial power supplies
Battery systems
Servo drive protection

Purchase Information

We support online purchase of the Bussmann 170M1316 High Speed Square Body Fuse. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.

Frequently Asked Questions

What is the Bussmann 170M1316? The 170M1316 is a high speed square body fuse in the Bussmann 170M series, rated 80 A at 690 V AC (IEC) / 700 V AC (UL).

What is the amperage rating of the 170M1316? The rated current is 80 A.

What is the voltage rating? The fuse is rated 690 V AC per IEC and 700 V AC per UL.

What is the breaking capacity? The breaking capacity is 200 kA.

What is the clearing I²t at 660 V? The clearing I²t is 2550 A²s at 660 V.

What class is the 170M1316? It is classified as aR.

What is the fuse size and mounting? It is size 000 with DIN 43653 U/80 bolted tag mounting and no indicator.

What is the pre-arc I²t? The pre-arc I²t is 380 A²s.

What is the watt loss? Watt losses are 19 W at rated current.

What applications does it protect? It is used for semiconductor, DC bus, DC drive, and power converter protection.

What should be verified before purchase? Confirm the catalog number, circuit voltage and current, available fault current, fuse size, mounting method, and whether an indicator is needed.
