Technical specifications, features, applications and purchasing information.
| Brand | SIEMENS |
| Model Number | 6ED1052-1FB08-0BA2 |
| Product Category | Programmable Logic Module |
| Product Family | LOGO! 8.4 |
| Module Designation | LOGO! 230RCE |
| Nominal Supply Voltage | 115/230 VAC or VDC |
| Permissible DC Supply Range | 100 to 253 VDC |
| AC Supply Frequency | 47 to 63 Hz |
| Number of Digital Inputs | 8 |
| Number of Digital Outputs | 4 |
| Digital Output Type | Relay |
| Maximum Relay Switching Current, Resistive Load | 10 A |
| Maximum Relay Switching Current, Inductive Load | 3 A |
The SIEMENS 6ED1052-1FB08-0BA2 LOGO! 230RCE combines eight digital inputs and four relay outputs for small-scale industrial automation and control applications. External fusing is required for relay output protection.
The logic module supports nominal 115 V or 230 V AC and DC supply systems, providing options for applications using compatible industrial control voltages.
The LOGO! 8.4 basic module supports programs containing up to 400 function blocks, enabling timers, logic operations, switching schedules and other configurable automation functions.
Built-in Ethernet communication and an integrated web server support compatible networked control applications, device monitoring and user-defined web pages.
The LOGO! 8.4 generation supports cloud connection and MQTT communication, allowing integration into appropriately configured networked monitoring and automation systems.
The integrated display provides local operating information, while compatible LOGO! expansion modules and standard microSD storage support application development and system configuration.
We support online purchase of the SIEMENS 6ED1052-1FB08-0BA2 Programmable Logic Module. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
What is SIEMENS 6ED1052-1FB08-0BA2?
It is a LOGO! 230RCE programmable logic module from the SIEMENS LOGO! 8.4 family, featuring an integrated display, eight digital inputs, four relay outputs and Ethernet communication.
What power supply does the module require?
The LOGO! 230RCE supports nominal 115 V or 230 V AC/DC supply configurations. Check the manufacturer wiring instructions and permitted operating ranges before installation.
How many digital inputs and outputs are provided?
The module includes eight digital inputs and four digital relay outputs.
What is the maximum relay output current?
SIEMENS specifies maximum switching currents of 10 A for resistive loads and 3 A for inductive loads. External protective fusing is necessary.
How many function blocks can the module support?
The LOGO! 230RCE supports up to 400 function blocks for its programmable logic application.
Does 6ED1052-1FB08-0BA2 have an integrated display?
Yes. This version includes an integrated display for local interaction and status information.
Does the module support Ethernet communication?
Yes. It includes an Ethernet interface and integrated web server for compatible networked applications.
Does the LOGO! 8.4 support MQTT?
Yes. SIEMENS identifies MQTT and cloud connectivity as functions supported by the LOGO! 8.4 basic modules.
Which programming software is required?
LOGO! Soft Comfort V8.4 or later is specified for this model. Confirm project compatibility when transferring applications from earlier versions.
Can additional digital inputs and outputs be added?
Yes. The logic module supports modular expansion using compatible SIEMENS LOGO! expansion modules within the applicable system limits.
How is the module mounted?
It mounts on a standard 35 mm DIN rail, occupies four spacing units and measures approximately 71.5 × 90 × 60 mm.
