Omron CP1L-L20DR-A Module with 20 I/O and Relay Outputs for Machine Control

Product Overview

Buy Omron CP1L-L20DR-A Module online. The Omron CP1L-L20DR-A is a CP1L Series programmable controller module with 20 integrated I/O points, including 12 digital inputs and 8 relay outputs. Its 100-240 VAC power supply, 5K-step program capacity, 10K-word data memory, and USB communication port support compact Industrial Automation and Industrial Control systems.

Designed for Machine Control and factory equipment, this module provides four encoder input channels with a maximum input frequency of 100 kHz. It supports up to 60 local I/O points through one expansion unit, providing configuration flexibility for control panels and manufacturing machinery.

The CP1L-L20DR-A is suitable for OEM Electrical Equipment, Automation Components, and compatible Replacement Parts requirements in established CP1L installations. Its integrated control functions make it applicable to a wide range of Industrial Applications requiring reliable PLC-based sequence control.

Technical Specifications & Features

• Brand: Omron
• Manufacturer Part Number: CP1L-L20DR-A
• Category: Module
• Product Series: CP1L
• Power Supply: 100-240 VAC
• Built-in I/O: 20 points
• Digital Inputs: 12
• Digital Outputs: 8
• Output Type: Relay
• Program Capacity: 5K steps
• Data Memory Capacity: 10K words
• Communication Port: USB
• Encoder Input Channels: 4
• Maximum Encoder Input Frequency: 100 kHz
• Maximum Local I/O Points: 60
• Maximum Expansion Units: 1
• Auxiliary Output: 24 VDC, 200 mA
• Dimensions: 90 x 86 x 85 mm
• Weight: 380 g
• Operating Temperature: 0 to 55°C

The relay-output configuration supports industrial control interfaces, while the built-in USB port provides a direct communication connection for programming and maintenance. The controller also includes a real-time clock and high-speed encoder input capability for automation tasks requiring accurate event counting and machine sequencing.

Its compact housing and support for one expansion unit allow control-system designers to balance panel space with additional I/O requirements. The integrated power supply, inputs, outputs, memory, and communication functions reduce the number of separate Automation Components required in smaller control systems.

Applications

The Omron CP1L-L20DR-A can be used in packaging machinery, material-handling systems, assembly equipment, production lines, and other Industrial Applications requiring compact PLC logic and relay output control. Typical functions include sequence control, sensor input processing, interlocking, counting, and general Machine Control.

This module is also applicable to control panels, manufacturing equipment, OEM systems, and maintenance of installed CP1L Industrial Automation systems. For Replacement Parts projects, verify the existing program, wiring, power supply, I/O arrangement, expansion units, and communication requirements before installation.

Bulk purchase and RFQ are available. Contact us for quantity pricing, lead time, and shipping options.
