Omron
Omron CJ2M-CPU31 CPU Module with EtherNet/IP for Industrial Automation
PRODUCT PRICE
USD
$496.90
0 pcs / pack
Available to order
Request a QuoteBulk Orders, Part Number Assistance, or Alternative Payment Options? Contact Our Team!
Shop with confidence
30-Day Risk-Free Returns & Exchanges
Shop with confidence. If for any reason you are not satisfied, you can take advantage of our hassle-free return and exchange service within 30 days. The seller covers all shipping costs for returns or exchanges—there are no extra shipping fees for you to pay, ensuring a worry-free shopping experience.
Payments
Available payment methods
💳 Need a Different Payment Method?Add your items to cart and contact our team before checkout. We'll help you explore available payment arrangements.
Service Guarantee
Estimated delivery
Ships from 4 U.S. Warehouses – Contact Us for Estimated Delivery Times.
PRODUCT DOCUMENTATION
Product Information
Technical specifications, features, applications and purchasing information.
Omron CJ2M-CPU31 CPU Module with EtherNet/IP for Industrial Automation
Product Overview
Buy Omron CJ2M-CPU31 Module online. The Omron CJ2M-CPU31 is a CJ2M-series programmable controller CPU module with a built-in EtherNet/IP port for Industrial Automation and Machine Control systems. It supports a 5K-step user program, 64K words of data memory, up to 2,560 local I/O points, and connection of up to 40 expansion units.
The CPU module provides EtherNet/IP, Ethernet TCP/IP, and USB communication interfaces. Its standard USB programming port enables direct connection to Omron support software, while the option board slot supports compatible serial communication boards for RS-232C or RS-422A/485 communication.
Designed for Industrial Control and general-purpose equipment, the CJ2M-CPU31 can be integrated with compatible CJ-series power supply, I/O, control, and communication units. It is suitable for OEM machinery, Electrical Equipment maintenance, Automation Components integration, and Replacement Parts requirements where the specified model is required.
Technical Specifications & Features
- Brand: Omron
- Manufacturer Part Number: CJ2M-CPU31
- Category: CPU Module
- Product Series: CJ2M
- Program Capacity: 5K steps
- Data Memory Capacity: 64K words
- Maximum Local I/O Points: 2,560
- Maximum Expansion Units: 40
- Maximum Expansion Racks: 3
- Logic Instruction Execution Time: 0.04 microseconds
- Current Consumption: 0.7 A at 5 VDC
- Mounting Type: Panel-mounted PLC system
- Connection Type: EtherNet/IP, Ethernet TCP/IP, USB, serial option board slot
- Dimensions: 90 mm × 62 mm × 84.5 mm
- Weight: 190 g
- Operating Temperature: 0 to 55 °C
The built-in EtherNet/IP interface supports network communication and integration with connected automation equipment, while the USB port provides convenient access for controller programming and maintenance. The modular CJ platform allows the CPU to be configured with compatible I/O and communication units according to the control system requirements.
Its compact construction, expandable I/O architecture, and compatibility with CJ-series Automation Components make the CJ2M-CPU31 suitable for reliable operation in industrial control panels and OEM equipment.
Applications
The Omron CJ2M-CPU31 is used in Industrial Applications such as production machinery, packaging equipment, assembly systems, material handling equipment, process control installations, and factory automation lines. It provides centralized PLC control for input processing, output control, sequence execution, equipment communication, and Machine Control tasks.
This CPU module is also suitable for Industrial Automation upgrades, control-panel maintenance, OEM system integration, and Replacement Parts projects involving compatible CJ-series Electrical Equipment. System compatibility and unit version requirements should be verified before installation.
Bulk purchase and RFQ are available. Contact us for quantity pricing, lead time, and shipping options.
