460 V Motor Rating
Designed for servo motion systems using the specified 460 V motor configuration.
Allen-Bradley
Allen-Bradley MPF-B310P-MJ72BA Food-Grade Servo Motor 460V 5000RPM
$3,225.47
Available
PRODUCT GALLERY
01 / 2
Product images for part identification
Allen-Bradley
Allen-Bradley MPF-B310P-MJ72BA Food-Grade Servo Motor 460V 5000RPM
PRODUCT PRICE
USD
$3,225.47
Available to order
Request a Quote
Need multiple units or help confirming a model?
Contact our team.
Free U.S. Shipping
Standard delivery
30-Day Returns
Subject to return policy
Bulk Purchase
Request volume quotes
Secure Checkout
Shopify-powered checkout
PRODUCT DOCUMENTATION
Product Information
Technical specifications, features, applications and purchasing information.
Technical Specifications
| Brand | Allen-Bradley |
| Model Number | MPF-B310P-MJ72BA |
| Product Category | Food-Grade AC Rotary Servo Motor |
| Product Family | MP-Series MPF |
| Rated Voltage | 460 V |
| Frame Size | 100 mm |
| Magnet Stack Length | 25.4 mm |
| Rated Speed | 5000 RPM |
| Continuous Stall Torque | 1.58 N·m |
| Motor Rated Output | 0.77 kW |
| Weight | 6.81 lbs (3.09 kg) |
Key Features
5000 RPM Rated Speed
The published motor specification lists a rated speed of 5000 RPM.
100 mm Frame Size
Uses a 100 mm frame with a 25.4 mm magnet stack length.
Absolute Encoder Feedback
Equipped with a multi-turn high-resolution encoder providing absolute feedback for supported motion-control configurations.
Keyed Shaft Extension
Features a keyed shaft extension for mechanical coupling designed around the specified shaft configuration.
Rotatable SpeedTEC Connector
Uses a right-angle SpeedTEC DIN connector that can rotate through 180 degrees for connection positioning.
Applications
- Food and beverage processing machinery
- Food packaging equipment
- Volumetric filling systems
- Form-fill-seal packaging machinery
- Automated material handling
- Industrial servo motion control
- Packaging line positioning systems
- Food-grade manufacturing automation
Purchase Information
We support online purchase of the Allen-Bradley MPF-B310P-MJ72BA Food-Grade AC Rotary Servo Motor. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
Frequently Asked Questions
What is Allen-Bradley MPF-B310P-MJ72BA?
It is an MP-Series MPF food-grade AC rotary servo motor designed for industrial motion-control applications.
What is the rated voltage?
The catalog configuration is rated at 460 V.
What is the maximum rated speed listed?
The published motor speed is 5000 RPM.
What is the motor frame size?
The specified frame size is 100 mm.
What is the magnet stack length?
The catalog specification lists a magnet stack length of 25.4 mm.
What feedback device does this motor use?
It uses a multi-turn high-resolution encoder with absolute feedback.
Does this motor include a brake?
No. The MPF-B310P-MJ72BA configuration is listed without a brake.
What type of shaft does the motor have?
The specified shaft configuration is a keyed shaft extension.
What connector is specified?
The motor uses a right-angle SpeedTEC DIN connector with 180-degree rotation capability.
What is the continuous stall torque?
The published continuous stall torque is 1.58 N·m.
What applications can this motor be considered for?
It can be considered for suitable food packaging, filling, form-fill-seal and automated material-handling machinery after the motion-system requirements have been checked.
What should be checked before ordering?
Verify the full catalog number, motor voltage, speed, torque requirements, encoder feedback, shaft dimensions, connector orientation, brake configuration and mounting arrangement.
Need help confirming a model?
Send us your part number and technical requirements.
