Technical specifications, features, applications and purchasing information.
| Brand | Allen-Bradley |
| Model Number | 889D-F8AB-10 |
| Product Category | M12 Cordset |
| Product Family | 889 DC Micro Cordsets and Patchcords |
| Product Bulletin | Bulletin 889 |
| Product Type | Single-Ended Sensor and Field Device Cordset |
| Connector Standard | DC Micro (M12) |
| First End Connector | M12 Female |
| First End Connector Orientation | Straight |
| First End Contact Configuration | 8-Pin Female |
| Second End Termination | Flying Leads, No Connector |
| Number of Conductors | 8 |
| Cable Length | 10 m (32.8 ft) |
| Conductor Size | 24 AWG |
| Approximate Conductor Cross-Section | 0.205 mm² |
| Cable Jacket Material | PVC, Oil Resistant |
| Cable Jacket Color | Black |
| Cable Shielding | Unshielded |
| Conductor Identification | IEC Standard Color Coding |
| Nominal Cable Diameter | 7.4 mm for 8-Conductor Cable |
| Minimum Bend Radius | 10 Times Cable Diameter |
| Approximate Minimum Bend Radius | 74 mm Based on 7.4 mm Cable Diameter |
| Connector Rated Current | 1.5 A |
| Maximum Assembly Rated Voltage, AC | 30 VAC |
| Maximum Assembly Rated Voltage, DC | 36 VDC |
| Connector Assembly Rating | 1.5 A at 30 VAC / 36 VDC |
| Cable Insulation Voltage Rating | 300 V; Not the Connector Assembly Operating Voltage |
| Protection Rating When Properly Mated | IP67 / IP69K |
| Enclosure Protection Classification | NEMA 6P |
| Washdown Rating | 1200 psi (8270 kPa) Under Specified Mated Conditions |
| Connector Coupling Nut | Epoxy-Coated Zinc |
| Connector Contact Material | Brass with Gold over Nickel Plating |
| Contact Surface | Gold |
| Connector Housing Material | Plastic |
| Molded Connector Material | Oil-Resistant PUR |
| Connector Approximate Diameter | 14 mm |
| Connector Approximate Length | 47 mm |
| Connection Method | Quick-Disconnect M12 Connector with Field-Wired Flying Leads |
| Cable End Configuration | Single Connector with Eight Free Conductors |
| Shield Connection | Not Provided |
| Application Compatibility | Compatible 8-Pin M12 Male Device Interfaces with Matching Pin Assignments |
| Associated Equipment | Selected Industrial Sensors, Safety Equipment and Field Devices |
| Product Lifecycle Status | Active |
| Manufacturer UPC | 611320705331 |
| Manufacturer Documentation | 889-TD002 Technical Data |
The Allen-Bradley 889D-F8AB-10 features a straight female 8-pin DC Micro M12 connector designed for compatible industrial field devices. Its connector configuration provides a detachable interface for equipment requiring an eight-contact M12 connection.
The 10 m (32.8 ft) cable assembly has an M12 female connector at one end and eight unterminated conductors at the other. The flying leads can be connected to suitable terminal blocks or control equipment according to the device wiring diagram.
Eight 24 AWG conductors use IEC standard color identification to support organized field wiring. The correct relationship between connector pin numbers and conductor colors must be checked against the manufacturer's pinout before connection.
The unshielded cable uses an oil-resistant black PVC jacket with an approximate 7.4 mm outside diameter. The manufacturer specifies a bend radius of ten times the cable diameter, helping installers plan appropriate routing and strain relief.
The M12 connector assembly carries IP67 and IP69K protection ratings when properly mated to compatible equipment. The manufacturer's specifications also identify NEMA 6P and washdown-related ratings under the specified installation conditions.
The connector assembly is rated for 1.5 A at a maximum of 30 VAC or 36 VDC. Gold-plated electrical contacts and a protected coupling nut support reliable connections in appropriately installed industrial sensor and control circuits.
We support online purchase of the Allen-Bradley 889D-F8AB-10 M12 Cordset. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
What is Allen-Bradley 889D-F8AB-10?
Allen-Bradley 889D-F8AB-10 is a Bulletin 889 DC Micro M12 cordset with an eight-pin straight female connector, a 10-meter black PVC cable and eight color-coded flying leads at the opposite end.
How long is the 889D-F8AB-10 cable?
The manufacturer specifies a cable length of 10 meters, equivalent to approximately 32.8 feet. The full catalog number identifies this particular length within the 889D-F8AB cordset family.
What connector does 889D-F8AB-10 use?
It has one straight female eight-pin DC Micro M12 connector. The mating equipment must have a compatible male connector with the correct mechanical interface and electrical pin assignments.
Does the second end have a connector?
No. The second end consists of eight flying leads without a connector. These conductors are intended for termination in compatible field wiring or control circuits using the applicable wiring diagram.
What cable material and conductor size are used?
The specified cable has a black, oil-resistant PVC jacket and eight unshielded 24 AWG conductors. The wires are identified using IEC standard color coding.
What is the voltage and current rating of 889D-F8AB-10?
The connector assembly is rated for 1.5 A at 30 VAC or 36 VDC. The separately listed 300 V cable insulation rating does not increase the permitted operating voltage of the complete connector assembly.
Is 889D-F8AB-10 shielded?
No. Rockwell Automation identifies this model as an unshielded cable assembly. Applications requiring a shielded cable must use a separately verified compatible product.
Is 889D-F8AB-10 waterproof?
The manufacturer lists IP67 and IP69K protection ratings for the properly mated connector assembly, together with NEMA 6P classification. Protection depends on correct mating, sealing and installation. The unterminated flying-lead end is not independently sealed by the M12 connector rating.
What is the difference between 889D-F8AB-10 and 889D-R8AB-10?
The 889D-F8AB-10 uses a straight eight-pin female M12 connector, while the 889D-R8AB-10 uses a right-angle female M12 connector. Both are listed in ten-meter configurations, but their connector orientations differ.
What is the difference between 889D-F8AB-10 and 889D-F8ABDM-10?
The 889D-F8AB-10 is a single-ended cordset with an M12 female connector and flying leads. The 889D-F8ABDM-10 is a double-ended patchcord configuration. Verify both connector ends before choosing a replacement.
Can 889D-F8AB-10 be used with safety light curtains?
Yes, where specified by the equipment manufacturer. Rockwell Automation lists 889D-F8AB-10 as a ten-meter eight-pin M12 receiver cordset in GuardShield light curtain connection documentation. The exact safety device model, wiring pinout and system requirements must be verified before installation.
What should be checked before ordering 889D-F8AB-10?
Verify the complete catalog number 889D-F8AB-10, eight-pin straight female M12 connector, 10-meter length, black PVC jacket, unshielded 24 AWG conductors, IEC wire color identification, flying-lead termination, 1.5 A connector rating, 30 VAC or 36 VDC maximum assembly voltage, required environmental protection and mating equipment pin assignments. For safety-related installations, follow the complete equipment manufacturer's wiring and validation instructions.
