DPDT Contact Arrangement
The 700-HA32A24 provides two changeover contacts in a DPDT, or 2 Form C, arrangement for industrial control switching.
Allen-Bradley 700-HA32A24 General Purpose Relay DPDT 10A 24V AC
Available in stock (400)
Regular price
$51.69
Sale price
Regular price
Shipping calculated at checkout.
Technical Specifications
| Brand | Allen-Bradley |
| Model Number | 700-HA32A24 |
| Product Category | General Purpose Relay |
| Series | 700-HA |
| Product Type | Tube Base Relay |
| Contact Configuration | DPDT (2 Form C) |
| Number of Changeover Contacts | 2 |
| Contact Rating | 10 A Standard Contact |
| Coil Voltage | 24 V AC, 50/60 Hz |
| Actuating Voltage Type | AC |
| Rated Thermal Current | 10 A at 240 V AC |
| Connection Type | Plug-In |
| Contact Material | AgNi |
| Electrical Life | Minimum 100,000 Operations |
| Degree of Protection | IP40 |
| Protection with Guarded Terminal Socket | IP20 |
| Width | 32.8 mm |
| Height | 54.1 mm |
| Depth | 36.5 mm |
Key Features
24V AC Coil
The relay uses a 24 V AC coil rated for both 50 Hz and 60 Hz control power systems.
10A Standard Contacts
The documented configuration uses standard contacts with a 10 A contact rating.
Plug-In Tube Base Design
The Bulletin 700-HA relay uses a plug-in tube base connection for installation with an appropriate relay socket.
AgNi Contact Material
The documented contact material for the 700-HA32A24 is silver-nickel, identified as AgNi.
General Purpose Control
The 700-HA series is designed for general purpose relay switching in industrial control and automation circuits.
Applications
- Industrial control panels
- Machine automation circuits
- Interposing relay applications
- Motor control circuits
- PLC interface circuits
- Production equipment controls
- Control cabinet assemblies
- General industrial switching circuits
Purchase Information
We support online purchase of the Allen-Bradley 700-HA32A24 General Purpose Relay. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
Frequently Asked Questions
What is Allen-Bradley 700-HA32A24?
The 700-HA32A24 is a Bulletin 700-HA general purpose tube base relay with DPDT contacts and a 24 V AC coil.
What coil voltage does 700-HA32A24 use?
The documented coil voltage is 24 V AC at 50/60 Hz.
What contact configuration does 700-HA32A24 have?
The relay uses a DPDT contact arrangement, providing two Form C changeover contacts.
What is the contact rating of 700-HA32A24?
The documented configuration uses 10 A standard contacts.
What is the rated thermal current?
Rockwell Automation lists a rated thermal current of 10 A at 240 V AC.
What connection type does 700-HA32A24 use?
The relay uses a plug-in connection for installation with an appropriate socket.
What contact material is used?
The documented contact material is AgNi silver-nickel.
What is the degree of protection?
The relay is documented as IP40, with IP20 protection specified when used with a guarded terminal socket.
What are the dimensions of 700-HA32A24?
The documented dimensions are 32.8 mm wide, 54.1 mm high and 36.5 mm deep.
Does 700-HA32A24 include additional relay options?
The product cutsheet identifies this catalog number as the configuration without additional relay options.
Can 700-HA32A24 be considered for an existing relay application?
It can be considered after the complete catalog number, 24 V AC coil, DPDT contact arrangement, 10 A contact rating and socket requirements have been checked against the existing control circuit.
What should be checked before ordering 700-HA32A24?
Check the complete model number, 24 V AC 50/60 Hz control voltage, DPDT contact arrangement, 10 A contact rating, plug-in connection and required socket against the intended application.
