7-Inch Widescreen Display
The 2713P-T7WD1 provides a 7 in widescreen color TFT LCD for machine visualization and operator interaction.
Allen-Bradley 2713P-T7WD1 PanelView 5310 HMI 7in Touch 24VDC 800x480
Available in stock (400)
Regular price
$948.23
Sale price
Regular price
Shipping calculated at checkout.
Technical Specifications
| Brand | Allen-Bradley |
| Model Number | 2713P-T7WD1 |
| Product Category | HMI Operator Interface |
| Product Family | PanelView 5310 |
| Operator Input | Touch |
| Display Size | 7 in Widescreen |
| Display Type | Color TFT LCD |
| Display Resolution | 800 x 480 WVGA |
| Color Depth | 24-bit Color Graphics |
| Nominal Input Voltage | 24 VDC (18-30 VDC) |
| Ethernet Port | One 10/100Base-T Ethernet Port |
| Supported Protocol | EtherNet/IP |
| RAM | 1 GB |
| User Storage | 1 GB Nonvolatile Storage |
| Typical Power Consumption | 9 W |
| Maximum Power Consumption | 13 W |
| Front Protection | IP66 |
Key Features
Touch Operator Input
The PanelView 5310 terminal uses a touch interface for operator input.
800 x 480 WVGA Resolution
The display provides an 800 x 480 WVGA resolution with 24-bit color graphics.
24 VDC Power
The terminal has a nominal 24 VDC input with a documented 18-30 VDC input range.
EtherNet/IP Communication
One 10/100Base-T Ethernet port supports EtherNet/IP communication with the control system.
Integrated Project Storage
The terminal provides 1 GB RAM and 1 GB of user-available nonvolatile storage for projects.
Applications
- Machine operator interface systems
- Production line visualization
- Process status monitoring
- Industrial equipment control interfaces
- Manufacturing system visualization
- EtherNet/IP automation networks
- Operator command and status displays
- Panel-mounted machine interfaces
Purchase Information
We support online purchase of the Allen-Bradley 2713P-T7WD1 HMI Operator Interface. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
Frequently Asked Questions
What is Allen-Bradley 2713P-T7WD1?
Allen-Bradley 2713P-T7WD1 is a PanelView 5310 HMI operator interface with a 7 in widescreen touch display.
What display size does 2713P-T7WD1 use?
The terminal has a 7 in widescreen display.
What is the display resolution of 2713P-T7WD1?
The documented display resolution is 800 x 480 WVGA.
What input voltage does 2713P-T7WD1 require?
The nominal input voltage is 24 VDC with a documented input range of 18-30 VDC.
What communication interface does 2713P-T7WD1 provide?
It provides one 10/100Base-T Ethernet port and supports EtherNet/IP communication.
How much memory does 2713P-T7WD1 provide?
The terminal provides 1 GB RAM and 1 GB of user-available nonvolatile storage.
What type of operator input does 2713P-T7WD1 use?
The terminal uses a touch operator interface.
What is the front protection rating of 2713P-T7WD1?
The documented front-side degree of protection is IP66.
Can 2713P-T7WD1 be considered for an existing HMI system?
It can be considered after the complete model number and technical requirements have been checked against the existing system requirements.
What should be checked before ordering 2713P-T7WD1?
Check the complete model number, 7 in display requirement, 24 VDC electrical requirements, 800 x 480 resolution, Ethernet communication and installation requirements before ordering.
