PowerFlex 525 Platform
The 25B-D030N114 is a PowerFlex 525 AC drive with embedded EtherNet/IP communication and safety functionality.
Allen-Bradley 25B-D030N114 PowerFlex 525 AC Drive 15kW 30A 380-480VAC
Available in stock (400)
Regular price
$1,062.74
Sale price
Regular price
Shipping calculated at checkout.
Technical Specifications
| Brand | Allen-Bradley |
| Model Number | 25B-D030N114 |
| Product Category | AC Drive |
| Product Family | PowerFlex 525 |
| Voltage Class | 380-480 VAC, 3 Phase |
| Output Current | 30 A |
| Normal Duty Power | 15 kW / 20 HP |
| Heavy Duty Power | 11 kW / 15 HP |
| Communication | Embedded EtherNet/IP |
| Safety | Integrated Safety |
| Frame Size | Frame D |
| Enclosure Type | IP20 NEMA / Open Type |
| EMC Filtering | Filter |
| Interface Module | Standard |
| Brake IGBT | Included |
| Frequency Rating | 50-60 Hz |
| Power Factor | 0.98 |
| User Interface | Integral Keypad with Potentiometer and LED Display |
Key Features
15 kW Normal Duty
The drive is rated at 15 kW / 20 HP for normal-duty operation and 11 kW / 15 HP for heavy-duty operation.
380-480 VAC Input
This catalog configuration is specified for 380-480 VAC three-phase power.
30 A Output
The documented output current rating for the 25B-D030N114 is 30 A.
Embedded EtherNet/IP
Embedded EtherNet/IP communication supports connection to applicable industrial automation networks.
Frame D Filtered Drive
This configuration uses a Frame D, IP20 NEMA / Open Type enclosure with EMC filtering.
Applications
- Variable-speed motor control
- Conveyor drive systems
- Packaging machinery
- Material handling equipment
- Production machinery
- Automated machine systems
- EtherNet/IP drive networks
- 380-480 VAC three-phase motor applications
Purchase Information
We support online purchase of the Allen-Bradley 25B-D030N114 AC Drive. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
Frequently Asked Questions
What is Allen-Bradley 25B-D030N114?
Allen-Bradley 25B-D030N114 is a PowerFlex 525 AC drive with embedded EtherNet/IP and safety functionality.
What is the normal-duty power rating of 25B-D030N114?
The documented normal-duty rating is 15 kW / 20 HP.
What is the heavy-duty power rating of 25B-D030N114?
The documented heavy-duty rating is 11 kW / 15 HP.
What voltage class does 25B-D030N114 use?
The documented voltage class is 380-480 VAC, three phase.
What is the output current of 25B-D030N114?
The documented output current rating is 30 A.
What communication does 25B-D030N114 provide?
The drive provides embedded EtherNet/IP communication.
What frame size does 25B-D030N114 use?
The documented frame size is Frame D.
What enclosure type does 25B-D030N114 use?
The drive is specified with an IP20 NEMA / Open Type enclosure.
Does 25B-D030N114 include EMC filtering?
Yes. This catalog configuration is specified with an EMC filter.
What should be checked before ordering 25B-D030N114?
Check the complete model number, 380-480 VAC three-phase supply, 30 A output rating, normal-duty and heavy-duty motor power requirements, EtherNet/IP communication, safety requirements and installation requirements before ordering.
