PowerFlex 4M Platform
The 22F-D2P5N113 is a PowerFlex 4M AC drive for variable-frequency motor-control applications.
1 / 8
Allen-Bradley
Allen-Bradley 22F-D2P5N113 PowerFlex 4M AC Drive 0.75kW 2.5A 480VAC
PRODUCT PRICE
USD
$230.46
0 pcs / pack
Available to order
Request a QuoteNeed multiple units or help confirming a model? Contact our team.
Payments
Available payment methods
Shop with confidence
30-Day Risk-Free Returns & Exchanges
Shop with complete confidence. Whatever the reason, enjoy hassle-free returns and exchanges within 30 days. We cover all shipping costs for both returns and exchanges—no extra shipping fees, no worries.
Service Guarantee
PRODUCT DOCUMENTATION
Product Information
Technical specifications, features, applications and purchasing information.
Technical Specifications
| Brand | Allen-Bradley |
| Model Number | 22F-D2P5N113 |
| Product Category | AC Drive |
| Product Family | PowerFlex 4M |
| Input Voltage | 480 VAC, 3 Phase |
| Output Current | 2.5 A |
| Motor Power | 0.75 kW / 1 HP |
| Frame Size | Frame A |
| Enclosure Type | IP20 NEMA / Open Type |
| Human Interface | LED Display, Fixed Digital Keypad |
| EMC Filtering | Internal CE Compliant Filter |
| Brake | No Brake Drive |
Key Features
0.75 kW Motor Rating
The drive is specified for a 0.75 kW / 1 HP motor power rating.
480 VAC Three Phase
This catalog configuration is specified for 480 VAC three-phase input power.
2.5 A Output
The documented output current rating for the 22F-D2P5N113 is 2.5 A.
Fixed Digital Keypad
The operator interface combines an LED display with a fixed digital keypad.
Filtered Frame A Design
This Frame A model uses an IP20 open enclosure and includes an internal CE compliant filter.
Applications
- Variable-speed motor control
- Conveyor drive systems
- Packaging machinery
- Material handling equipment
- Production machinery
- Automated machine systems
- General-purpose AC motor control
- 480 VAC three-phase motor applications
Purchase Information
We support online purchase of the Allen-Bradley 22F-D2P5N113 AC Drive. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
Frequently Asked Questions
What is Allen-Bradley 22F-D2P5N113?
Allen-Bradley 22F-D2P5N113 is a PowerFlex 4M AC drive.
What is the motor power rating of 22F-D2P5N113?
The documented motor power rating is 0.75 kW / 1 HP.
What input voltage does 22F-D2P5N113 use?
The drive is specified for 480 VAC three-phase input power.
What is the output current of 22F-D2P5N113?
The documented output current rating is 2.5 A.
What frame size does 22F-D2P5N113 use?
The documented frame size is Frame A.
What enclosure type does 22F-D2P5N113 use?
The drive is specified with an IP20 NEMA / Open Type enclosure.
What operator interface does 22F-D2P5N113 have?
It is equipped with an LED display and fixed digital keypad.
Does 22F-D2P5N113 include an EMC filter?
Yes. This configuration includes an internal CE compliant filter.
Does 22F-D2P5N113 have a brake drive?
No. The documented configuration is specified as a no-brake drive.
What should be checked before ordering 22F-D2P5N113?
Check the complete model number, 480 VAC three-phase supply, 2.5 A output rating, 0.75 kW / 1 HP motor requirements, Frame A enclosure, filter configuration and installation requirements before ordering.
Need help confirming a model?
Send us your part number and technical requirements.
