Technical specifications, features, applications and purchasing information.
| Brand | Allen-Bradley |
| Model | 22A-B012N104 |
| Product Category | Variable Frequency Drive (VFD) |
| Manufacturer | Rockwell Automation |
| Product Family | PowerFlex 4 |
| Drive Type | Adjustable Frequency AC Drive |
| Rated Motor Power | 2.2 kW |
| Rated Motor Horsepower | 3 HP |
| Nominal Input Voltage | 200 to 240 VAC, 240 V Class |
| Input Phase | Three-Phase |
| Input Frequency | 50/60 Hz |
| Rated Output Current | 12 A |
| Output Type | Variable-Frequency Three-Phase AC |
| Motor Control Method | Volts-per-Hertz with Slip Compensation |
| Programmable Output Frequency | 0 to 240 Hz |
| Integrated Human Interface | LED Display and Fixed Digital Keypad |
| Communication Interface | Integrated RS485 (DSI) |
| Serial Communication | Modbus RTU Through RS485 DSI, Subject to Configuration |
| Analog Voltage Input | 0 to 10 VDC |
| Analog Current Input | 4 to 20 mA |
| Digital Input Logic | 24 VDC Source or Sink, Configurable |
| Programmable Relay Output | 1 Form C Relay |
| Motor Overload Protection | Electronic Overload Protection |
| Mounting Style | Panel Mount |
| Frame Size | B |
| Enclosure Protection Rating | IP20 |
| NEMA/UL Enclosure Type | Type Open |
| Integrated EMC Filter | No CE-Compliant EMC Filter |
| Catalog Family Code | 22A, PowerFlex 4 |
| Catalog Voltage Code | B, 240 V Class |
| Catalog Current Code | 012, 12 A |
| Catalog Enclosure Code | N, IP20 Panel Mount |
| Human Interface Configuration | Fixed Digital Keypad |
| Power Factor | 0.98, Manufacturer Product Specification |
| UPC | 662453979618 |
| Lifecycle Status | Discontinued |
| Manufacturer Discontinuation Date | June 30, 2025 |
| Manufacturer-Listed Replacement | 25A-B011N104, Engineering Replacement |
| Replacement Product Family | PowerFlex 523 |
| Replacement Output Current | 11 A, Different from the 12 A Existing Drive |
The Allen-Bradley 22A-B012N104 PowerFlex 4 adjustable frequency drive is designed for compatible three-phase AC motors. It operates from a 200–240 VAC three-phase supply and provides a rated output current of 12 A for 2.2 kW (3 HP) motor applications.
The PowerFlex 4 series provides volts-per-hertz motor control with slip compensation. Programmable frequency, acceleration and deceleration settings support adjustable-speed operation in industrial machinery.
A fixed digital keypad and LED display provide local access to drive configuration, operating status and diagnostic information. This supports commissioning, parameter adjustment and maintenance of installed PowerFlex 4 drives.
The integrated RS485 DSI interface supports compatible industrial serial communication, including Modbus RTU when properly configured. It enables the drive to communicate with suitable external controllers and monitoring systems.
The drive provides electronic motor overload protection, DC bus voltage monitoring and an internal brake IGBT. Applications requiring external braking resistors, additional circuit protection or EMC filtering must be engineered according to the manufacturer's instructions.
The 22A-B012N104 features a Frame B panel-mounted enclosure rated IP20, NEMA/UL Type Open. The configuration includes a fixed keypad and no integrated CE-compliant EMC filter, making cabinet installation and electrical compatibility important considerations.
We support online purchase of the Allen-Bradley 22A-B012N104 Variable Frequency Drive. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
What is the Allen-Bradley 22A-B012N104?
It is a Rockwell Automation PowerFlex 4 variable frequency drive rated for 2.2 kW (3 HP) and 12 A, with 240 V-class three-phase input, an integrated digital keypad and RS485 communication.
What motor power does this drive support?
The manufacturer specifies a rated motor power of 2.2 kW, equivalent to 3 HP. The connected motor must also meet the drive's rated current and operating requirements.
What input voltage is required?
The drive is designed for a nominal 200–240 VAC three-phase supply at 50/60 Hz. Verify supply tolerance requirements using the applicable PowerFlex 4 user manual.
What is the rated output current?
The manufacturer specifies a 12 A output current rating for catalog number 22A-B012N104.
Is this a single-phase or three-phase input drive?
It is a three-phase input drive intended for compatible three-phase AC motors. It should not be confused with single-phase-input PowerFlex 4 variants.
What motor control method does PowerFlex 4 use?
The PowerFlex 4 supports volts-per-hertz control with slip compensation, providing configurable frequency control for compatible AC motors.
Does the drive include a keypad?
Yes. It has an integrated LED display and fixed digital keypad for parameter programming, drive monitoring and fault diagnostics.
Does the 22A-B012N104 support RS485?
Yes. It includes an RS485 DSI communication interface. Modbus RTU communication is supported through compatible wiring and configuration.
Does the drive support dynamic braking?
Yes. Rockwell Automation lists an internal brake IGBT for this model. An appropriately rated external braking resistor and protective components may be needed for applications requiring dynamic braking.
What is the enclosure protection rating?
The drive uses a Frame B, IP20, NEMA/UL Type Open panel-mounted enclosure. Installation inside an appropriate industrial electrical cabinet is required for environmental protection.
Does this model have an integrated EMC filter?
No. The manufacturer specifies that the 22A-B012N104 has no integrated CE-compliant EMC filter. External filtering may be required for particular installations.
Is the Allen-Bradley 22A-B012N104 discontinued?
Yes. Rockwell Automation lists June 30, 2025 as the discontinuation date. The model remains relevant for servicing equipment designed around the PowerFlex 4 drive.
What replacement does Rockwell Automation recommend?
Rockwell Automation identifies 25A-B011N104 from the PowerFlex 523 family as an engineering replacement. It has an 11 A output rating and is not automatically a direct drop-in replacement for the 12 A PowerFlex 4 drive.
Can 25A-B011N104 directly replace 22A-B012N104?
An engineering review is required. Check the connected motor's full-load current, drive overload capacity, power and control wiring, parameter mapping, communication setup, enclosure dimensions and installation requirements before substitution.
What is the difference between 22A-B012N104 and 22A-B017N104?
Both belong to the PowerFlex 4 family and use 240 V-class three-phase input. The 22A-B012N104 is rated 2.2 kW (3 HP) and 12 A, while the 22A-B017N104 is rated 3.7 kW (5 HP) and belongs to a higher output-current class.
What should be checked before ordering?
Confirm the exact 22A-B012N104 catalog number, 2.2 kW (3 HP) motor rating, 200–240 VAC three-phase supply, 12 A output current, Frame B IP20 panel mounting, integrated LED keypad, RS485 DSI communication, braking requirements, EMC filter configuration and compatibility with the existing motor and control cabinet.
