Technical specifications, features, applications and purchasing information.
| Brand | Allen-Bradley |
| Model | 2198-H008-ERS2 |
| Product Category | Servo Drive |
| Manufacturer | Rockwell Automation |
| Product Series | Kinetix 5500 |
| Product Description | Kinetix 5500 Servo Drive with Integrated Safety over EtherNet/IP |
| Drive Configuration | Single-Axis AC Servo Drive |
| Frame Size | Frame 1 |
| Nominal Input Voltage, Single-Phase | 240 VAC |
| Single-Phase Input Voltage Range | 195 to 264 VAC RMS |
| Nominal Input Voltage, Three-Phase | 240 VAC or 480 VAC |
| Three-Phase Input Voltage Range, 240 V Class | 195 to 264 VAC RMS |
| Three-Phase Input Voltage Range, 480 V Class | 324 to 528 VAC RMS |
| Continuous Output Power at 240 V Single-Phase | 0.5 kW |
| Continuous Output Power at 240 V Three-Phase | 0.8 kW |
| Continuous Output Power at 480 V Three-Phase | 1.6 kW |
| Continuous Output Current, 0-Peak | 3.5 A |
| Continuous Output Current, RMS | 2.5 A |
| Peak Output Current, 0-Peak | 8.8 A |
| Peak Output Current, RMS | 6.25 A |
| Rated Apparent Output Power, 230 V Class | 1.0 kVA |
| Control Power Supply | 24 VDC, Separate from Main AC Input |
| 24 VDC Control Current, Motor Without Brake | 0.4 A |
| 24 VDC Control Current, 2 A Motor Brake | 2.4 A |
| 24 VDC Inrush Current | 2.0 A, Less Than 30 ms |
| Communication Network | EtherNet/IP |
| Motion Control Protocol | Integrated Motion on EtherNet/IP |
| Ethernet Connectivity | Dual-Port Industrial Ethernet Interface |
| Network Topology Support | Compatible Linear and Device Level Ring Installations |
| Safety Option | Integrated Safety over EtherNet/IP |
| Safety Function | Safe Torque Off (STO) |
| STO Control Method | Network-Based Safety Commands with Compatible Safety Controller |
| Hardwired STO Connector | Not Used on ERS2 Integrated Safety Model |
| Safety Integration | Compatible GuardLogix or Compact GuardLogix Safety Control System |
| Motor Feedback | Hiperface DSL with Compatible Motor and Feedback Connections |
| Native Motor System Compatibility | Compatible Kinetix VP Servo Motors |
| Additional Motor Feedback Option | 2198-H2DCK Converter Kit for Selected Compatible Motors |
| Included Motor Feedback Connector Kit | 2198-KITCON-DSL According to Standard Installation Documentation |
| Maximum Velocity Loop Bandwidth | 300 Hz |
| Current Loop Bandwidth | 1000 Hz |
| Internal Shunt Continuous Power | 30 W |
| Internal Shunt Resistance | 100 Ω |
| Typical Electrical Efficiency | Approximately 97% |
| Multi-Axis Power Arrangement | Supports Compatible Shared AC/DC Bus Systems |
| Mounting Method | Vertical Panel Mounting |
| Frame Width | 50 mm |
| Overall Height, Standard Frame 1 | 215 mm |
| Overall Depth, Standard Feedback Connector Arrangement | 226 mm |
| Minimum Recommended Cabinet Depth | 300 mm |
| Recommended Clearance Above Drive | 40 mm |
| Recommended Clearance Below Drive | 40 mm |
| Panel Mounting Hardware | M4 or #8-32 Steel Machine Screws |
| Maximum Mounting Screw Torque | 2.0 N·m |
| Operating Ambient Temperature | 0 to +50°C |
| Storage Temperature | -40 to +70°C |
| Relative Humidity | 5% to 95%, Noncondensing |
| Maximum Altitude Without Derating | 1000 m |
| Typical Unit Weight | Approximately 1.4 kg |
| Product UPC | 885630902661 |
| Product Lifecycle Status | Active, Rockwell Automation Product Catalog |
| Related Hardwired STO Model | 2198-H008-ERS |
| Related Higher-Current Model | 2198-H015-ERS2 |
| Manufacturer User Manual | Rockwell Automation Publication 2198-UM001 |
| Manufacturer Installation Instructions | Rockwell Automation Publication 2198-IN001 |
| Manufacturer Technical Data | Rockwell Automation Publication KNX-TD003 |
| Manufacturer Product Reference | https://www.rockwellautomation.com/en-us/products/details.2198-H008-ERS2.html |
The Allen-Bradley 2198-H008-ERS2 Kinetix 5500 servo drive supports multiple input configurations. Its continuous output power is rated at 0.5 kW with 240 V single-phase input, 0.8 kW with 240 V three-phase input and 1.6 kW with 480 V three-phase input.
The drive provides 3.5 A continuous and 8.8 A peak output current when expressed as zero-to-peak values. The corresponding RMS ratings are 2.5 A continuous and 6.25 A peak, supporting appropriately sized servo motors and dynamic motion applications.
The ERS2 configuration supports integrated Safe Torque Off through an EtherNet/IP safety connection with a compatible safety controller. This allows safety and motion functions to be coordinated within an appropriately designed Rockwell Automation control system.
Dual Ethernet ports enable integration with compatible Logix controllers using Integrated Motion on EtherNet/IP. Supported network arrangements simplify communication between the servo drive and controller in coordinated motion systems.
The Kinetix 5500 platform supports compatible Kinetix VP servo motors with Hiperface DSL feedback and single-cable motor connection technology. Selected additional motor families can be supported through the appropriate feedback converter and accessories.
The 50 mm-wide Frame 1 drive supports compact vertical panel installation and compatible shared-bus multi-axis arrangements. Separate 24 VDC control power, integrated shunt capability and modular connections assist with industrial motion system design and maintenance.
We support online purchase of the Allen-Bradley 2198-H008-ERS2 Servo Drive. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
What is the Allen-Bradley 2198-H008-ERS2?
It is a Rockwell Automation Kinetix 5500 Frame 1 servo drive with Integrated Motion on EtherNet/IP, network-based Safe Torque Off functionality and support for compatible AC servo motors.
What input voltage does the 2198-H008-ERS2 support?
It supports 195 to 264 VAC RMS single-phase or three-phase input and 324 to 528 VAC RMS three-phase input. Rated power output depends on the selected voltage and phase configuration.
What is the rated output power?
The manufacturer specifies 0.5 kW at 240 V single-phase, 0.8 kW at 240 V three-phase and 1.6 kW at 480 V three-phase. The 1.6 kW figure applies to the 480 V three-phase configuration.
Is the continuous output current 3.5 A or 2.5 A?
Both values are correct under different measurement conventions. The manufacturer specifies 3.5 A continuous as a zero-to-peak value and 2.5 A continuous as an RMS value.
What is the maximum peak output current?
The rated peak output current is 8.8 A zero-to-peak or 6.25 A RMS under the applicable manufacturer conditions. Peak current must not be treated as the continuous output rating.
What is the difference between 2198-H008-ERS and 2198-H008-ERS2?
Both are Kinetix 5500 drives with the same basic power class. The 2198-H008-ERS uses hardwired Safe Torque Off connections, while the 2198-H008-ERS2 implements integrated Safe Torque Off over EtherNet/IP. Their safety integration requirements differ.
Does this drive support CIP Safety?
Yes. The ERS2 model supports integrated safety over EtherNet/IP, including Safe Torque Off commands through a compatible safety controller. The full safety system must be designed and validated for the required safety performance.
Can the 2198-H008-ERS2 use a hardwired STO connector?
The ERS2 model does not use the hardwired STO connector provided for ERS variants. Its integrated STO functionality is controlled through the appropriate network safety configuration.
Does the servo drive support EtherNet/IP?
Yes. It supports Integrated Motion on EtherNet/IP through its dual-port Ethernet interface. The controller and communication configuration must support the required motion and safety connections.
Does the drive require a separate 24 VDC supply?
Yes. Separate 24 VDC control power is required. Rockwell Automation specifies 0.4 A control current without a motor brake and 2.4 A with the referenced 2 A motor-brake configuration.
Which servo motors are compatible?
The Kinetix 5500 is designed for compatible Kinetix VP servo motors using Hiperface DSL feedback. Certain other Rockwell Automation motor and actuator families can be used with supported conversion accessories. Verify the exact motor catalog number using the system design guide.
Does the 2198-H008-ERS2 support multiple servo axes?
One drive controls one servo axis. Compatible Kinetix 5500 drives can be installed together in multi-axis configurations using supported shared AC/DC bus connections and coordinated Logix motion control.
What are the physical dimensions?
The standard Frame 1 housing is approximately 50 mm wide, 215 mm high and 226 mm deep with the specified feedback connector arrangement. Additional clearance is required for cables and cabinet ventilation.
What is the operating temperature range?
The specified ambient operating range is 0 to +50°C. Rockwell Automation recommends 40 mm clearance above and below the vertically mounted drive for airflow and installation.
Is the 2198-H008-ERS2 discontinued?
Rockwell Automation currently identifies the 2198-H008-ERS2 as an active product in its catalog. Product lifecycle classifications may change, so confirm the latest status when planning a new system or maintenance program.
What should be checked before ordering?
Confirm the exact catalog number 2198-H008-ERS2, Kinetix 5500 Frame 1 configuration, single-phase or three-phase supply, power rating for the intended supply voltage, continuous RMS and peak current requirements, integrated CIP Safety STO architecture, compatible motion controller, motor and Hiperface DSL feedback, 24 VDC control supply, wiring accessories, mounting dimensions and existing system firmware compatibility.
Send us your part number and technical requirements.
