PowerFlex 700 Platform
The 20BD027A0AYNAND0 is a PowerFlex 700 adjustable-frequency AC drive for three-phase industrial motor control applications.
1 / 9
Allen-Bradley
Allen-Bradley 20BD027A0AYNAND0 PowerFlex 700 AC Drive 480V 27A 20HP
PRODUCT PRICE
USD
$3,720.16
0 pcs / pack
Available to order
Request a QuoteNeed multiple units or help confirming a model? Contact our team.
Shop with confidence
30-Day Risk-Free Returns & Exchanges
Shop with confidence. If for any reason you are not satisfied, you can take advantage of our hassle-free return and exchange service within 30 days. The seller covers all shipping costs for returns or exchanges—there are no extra shipping fees for you to pay, ensuring a worry-free shopping experience.
Payments
Available payment methods
Service Guarantee
Estimated delivery
Ships from 4 U.S. Warehouses – Contact Us for Estimated Delivery Times.
PRODUCT DOCUMENTATION
Product Information
Technical specifications, features, applications and purchasing information.
Technical Specifications
| Brand | Allen-Bradley |
| Model Number | 20BD027A0AYNAND0 |
| Product Category | AC Drive |
| Series | PowerFlex 700 |
| Input Voltage | 480 V AC, 3 Phase |
| Output Current | 27 A |
| Normal Duty Power | 20 HP |
| Heavy Duty Power | 15 HP |
| Frame Size | Frame 2 |
| Enclosure | IP20 / Type 1 with conformal coating |
| Control | Vector Control with 120 V I/O |
| Feedback | No Feedback |
| HIM | No HIM, Blank Plate |
| Communication Module | No Communication Module |
| Brake IGBT | Installed |
| Drive Mounted Brake Resistor | Not Included |
| EMC Filtering | Second Environment Filter |
| Continuous Output Current | 27 A |
| 1-Minute Output Current | 33 A |
| 3-Second Output Current | 44 A |
| UPC | 820919021244 |
Key Features
480 V Three-Phase
This catalog configuration is specified for a 480 V AC three-phase power supply.
27 A Output
The drive has a 27 A continuous output rating, with documented short-duration ratings of 33 A for one minute and 44 A for three seconds.
20 HP Normal Duty
The documented motor ratings are 20 HP for normal-duty operation and 15 HP for heavy-duty operation.
Vector Control
This configuration uses vector control with 120 V I/O and is specified without a feedback option.
Brake IGBT Installed
The drive configuration includes a brake IGBT while a drive-mounted brake resistor is not included.
Applications
- Industrial AC motor speed control
- Conveyor drive systems
- Material handling machinery
- Pump and fan applications
- Packaging and processing equipment
- Production machinery
- Industrial machine automation
- Variable-speed motor control systems
Purchase Information
We support online purchase of the Allen-Bradley 20BD027A0AYNAND0 AC Drive. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
Frequently Asked Questions
What is Allen-Bradley 20BD027A0AYNAND0?
It is a PowerFlex 700 adjustable-frequency AC drive for industrial three-phase motor control applications.
What is the input voltage?
The documented input voltage is 480 V AC, three phase.
What is the continuous output current?
The continuous output current is 27 A.
What are the short-duration output current ratings?
The documented ratings are 33 A for one minute and 44 A for three seconds.
What is the normal-duty power rating?
The documented normal-duty rating is 20 HP.
What is the heavy-duty power rating?
The documented heavy-duty rating is 15 HP.
What frame size does this drive use?
The 20BD027A0AYNAND0 uses a Frame 2 configuration.
What enclosure configuration is specified?
The documented enclosure is IP20 / Type 1 with conformal coating.
What control configuration does it use?
This catalog number specifies vector control with 120 V I/O and no feedback option.
Does it include a HIM or communication module?
The documented configuration has no HIM and uses a blank plate. No communication module is included.
Does it include braking hardware?
A brake IGBT is installed, while a drive-mounted brake resistor is not included.
Can 20BD027A0AYNAND0 replace another AC drive?
It can be considered after the complete model number and technical requirements have been checked. Input voltage, current, duty rating, frame size, enclosure, control, I/O and installed options should be verified against existing system requirements.
