12 Embedded I/O Points
The Micro810 controller provides eight inputs and four digital outputs for compact machine control and programmable switching applications.
Allen-Bradley
Allen-Bradley Brand New 2080-LC10-12QBB PLC Controller
$157.64
Available
PRODUCT GALLERY
01 / 9
Product images for part identification
Allen-Bradley
Allen-Bradley Brand New 2080-LC10-12QBB PLC Controller
PRODUCT PRICE
USD
$157.64
Available to order
Request a Quote
Need multiple units or help confirming a model?
Contact our team.
Free U.S. Shipping
Standard delivery
30-Day Returns
Subject to return policy
Bulk Purchase
Request volume quotes
Secure Checkout
Shopify-powered checkout
PRODUCT DOCUMENTATION
Product Information
Technical specifications, features, applications and purchasing information.
Technical Specifications
| Brand | Allen-Bradley |
| Model Number | 2080-LC10-12QBB |
| Product Category | PLC Controller |
| Product Family | Micro810 |
| Controller Series | Micro800 |
| Controller Type | 12-Point Programmable Smart Relay Controller |
| Total Embedded I/O | 12 Points |
| Total Inputs | 8 Points |
| Digital-Only Inputs | 4 Points |
| Configurable Analog/Digital Inputs | 4 Points |
| Digital Input Voltage | 12/24 VDC or VAC |
| Analog Input Signal | 0-10 VDC |
| Analog Input Resolution | 10-bit |
| Total Outputs | 4 Points |
| Digital Output Type | 24 VDC Source |
| Output Current per Point | 1 A Maximum at 30°C; 0.5 A Maximum at 55°C |
| Output User Supply Voltage | 10-26.4 VDC |
| Controller Supply Voltage | 12/24 VDC Class 2 |
| Controller Supply Voltage Range | 11.4-26.4 VDC |
| Power Consumption | 3 W |
| Programming Software | Connected Components Workbench |
| USB Programming | Supported via Optional USB Adapter |
| Optional Operator Interface | Micro800 1.5-inch LCD and Keypad Module |
| Module Support | USB Adapter and LCD Module |
| Enclosure Protection | IP20 |
| Dimensions (H × W × D) | 91 × 75 × 59 mm |
| Approximate Shipping Weight | 0.203 kg |
Key Features
Configurable Analog Inputs
Four input points can be configured for 0-10 VDC analog signals or used as digital inputs, depending on the application requirements.
24VDC Source Outputs
The controller includes four DC source outputs with documented current ratings of 1 A per point at 30°C and 0.5 A per point at 55°C.
12/24VDC Controller Supply
The controller uses a Class 2 DC power supply with a documented operating supply range of 11.4 to 26.4 VDC.
Programmable Logic Functions
The Micro810 platform supports programmable control functions through Connected Components Workbench software and configuration using the optional LCD module.
Compact Controller Dimensions
The documented dimensions are 91 × 75 × 59 mm, with DIN rail and panel installation arrangements described in the controller manual.
Applications
- Compact industrial machine control
- Programmable relay logic applications
- Machine sequence and timing control
- Low-voltage DC output switching
- Industrial equipment status monitoring
- 0-10 VDC analog signal monitoring
- Small automation control panels
- Equipment control and maintenance systems
Purchase Information
We support online purchase of the Allen-Bradley 2080-LC10-12QBB PLC Controller. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
Frequently Asked Questions
What is Allen-Bradley 2080-LC10-12QBB?
Allen-Bradley 2080-LC10-12QBB is a Micro810 programmable smart relay controller with 12 embedded I/O points, including eight inputs and four 24 VDC source outputs.
How many inputs and outputs does 2080-LC10-12QBB provide?
The controller provides eight inputs and four outputs, for a total of 12 embedded I/O points.
Can the controller use analog inputs?
Yes. Four of the eight input points can be configured as 0-10 VDC analog inputs instead of digital inputs.
What is the analog input resolution?
The documented analog input resolution is 10-bit.
What type of digital outputs does 2080-LC10-12QBB use?
The controller provides four 24 VDC source outputs. These are DC outputs rather than relay contacts.
What is the output current rating?
The documented maximum output current per point is 1 A at 30°C and 0.5 A at 55°C. Load requirements must be checked against the output specifications.
What power supply does 2080-LC10-12QBB require?
The controller uses a 12/24 VDC Class 2 supply with a documented operating voltage range of 11.4-26.4 VDC.
What is the controller power consumption?
The documented power consumption is 3 W.
Which software is used to program 2080-LC10-12QBB?
The Micro810 controller can be programmed using Connected Components Workbench software.
Does 2080-LC10-12QBB support USB programming?
Yes. USB programming is supported through the optional Micro810 USB adapter module.
Can an LCD module be used with 2080-LC10-12QBB?
Yes. The Micro810 supports an optional 1.5-inch LCD and keypad module for supported configuration, monitoring and data backup functions.
What should be checked before ordering 2080-LC10-12QBB?
Verify the complete catalog number, 12/24 VDC supply requirements, eight-input and four-source-output configuration, analog input requirements, DC output load ratings, programming accessories and installation dimensions against the existing system documentation.
