Allen-Bradley 1769-IF8 CompactLogix 8 Channel Analog Input Module
Available in stock (200)
Allen-Bradley 1769-IF8 Analog Input Module
8-channel analog current and voltage input module for industrial automation, control system expansion, equipment maintenance, and replacement procurement.
Technical Specifications
| Brand | Allen-Bradley |
| Model Number | 1769-IF8 |
| Product Category | Analog Input Module |
| Number of Analog Inputs | 8 |
| Input Type | Current / Voltage |
| Current Input Ranges | 0 to 20 mA / 4 to 20 mA |
| Voltage Input Ranges | -10 to +10 VDC / 0 to 10 VDC / 0 to 5 VDC / 1 to 5 VDC |
| Input Configuration | Single-Ended / Differential |
| Analog Input Resolution | 16 Bit Signed |
| Bus Current Draw | 120 mA @ 5 VDC / 70 mA @ 24 VDC |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | Up to 95% RH |
Product Overview
Allen-Bradley 1769-IF8 is an 8-channel analog input module designed to receive current and voltage signals in compatible industrial control systems. Its supported signal ranges include commonly used 0 to 20mA and 4 to 20mA current signals together with multiple DC voltage ranges.
The module provides eight analog input channels and supports single-ended or differential input configurations. Published technical information specifies 16-bit signed analog input resolution, providing a defined interface for acquiring analog process and equipment signals within a compatible control architecture.
For maintenance, system expansion, or replacement procurement, engineers and purchasing teams should verify the complete 1769-IF8 catalog number, controller and I/O architecture, input signal requirements, wiring configuration, available power capacity, firmware and existing system documentation before ordering.
Key Features
8 Analog Inputs
Eight analog input channels provide a structured interface for receiving multiple field signals within a compatible control system.
Current Inputs
Supports commonly used 0 to 20mA and 4 to 20mA analog current input ranges.
Voltage Inputs
Supports multiple DC voltage ranges including -10 to +10V, 0 to 10V, 0 to 5V and 1 to 5V.
16-Bit Resolution
Published technical data specifies 16-bit signed analog input resolution.
Configurable Channels
Individual channels can be configured according to the required analog input application and system requirements.
1769-IF8 Identification
The complete catalog number provides a clear reference for engineering documentation, maintenance records and purchasing inquiries.
Applications
- Industrial automation control systems
- Analog process signal acquisition
- 4 to 20mA transmitter signal input
- Voltage signal monitoring
- Pressure and flow measurement systems
- Level and process monitoring
- Machine control applications
- Control system maintenance and expansion
Product Advantages
Multiple Signal Ranges
Support for both current and voltage input ranges provides defined options for different analog field-signal requirements.
Eight-Channel Configuration
Eight input channels allow multiple analog signals to be incorporated into a compatible control system through one module.
Clear Model Identification
The 1769-IF8 catalog number provides a precise reference for purchasing inquiries, BOM records and maintenance documentation.
Procurement Verification
Published channel, signal-range and power data provide useful references when checking requirements before purchasing.
Purchase Information
Allen-Bradley 1769-IF8 Analog Input Module can be considered for industrial control system maintenance, expansion, replacement planning and purchasing inquiries. Before ordering, confirm the complete 1769-IF8 catalog number, required number of channels, current or voltage signal ranges, input configuration, controller architecture, available power capacity and wiring requirements against the existing control system documentation.
Other Allen-Bradley 1769 analog modules can have different channel counts, signal types and electrical specifications. Always use the complete 1769-IF8 catalog number when preparing a quotation request or purchasing requirement.
Frequently Asked Questions
What is Allen-Bradley 1769-IF8?
Allen-Bradley 1769-IF8 is an 8-channel analog current and voltage input module for compatible industrial control systems.
How many analog inputs does 1769-IF8 have?
The module provides eight analog input channels.
Does 1769-IF8 support 4 to 20mA signals?
Yes. Published specifications include both 0 to 20mA and 4 to 20mA current input ranges.
What voltage input ranges does 1769-IF8 support?
Published specifications include -10 to +10VDC, 0 to 10VDC, 0 to 5VDC and 1 to 5VDC ranges.
What is the input resolution?
Published technical information specifies 16-bit signed analog input resolution.
What is the bus current draw?
Published product data specifies 120mA at 5VDC and 70mA at 24VDC.
What is the operating temperature range?
Published technical information specifies an operating temperature range of 0°C to 60°C.
Can 1769-IF8 be used for process instrumentation?
The supported analog current and voltage ranges can be used to receive signals from compatible field instrumentation when the complete system configuration and wiring requirements have been verified.
Can 1769-IF8 be considered for replacement projects?
It can be considered after the complete catalog number, controller architecture, signal ranges, power requirements, wiring and system configuration have been checked against the existing installation.
What should be checked before ordering 1769-IF8?
Check the complete 1769-IF8 catalog number, controller and I/O architecture, required signal ranges, channel configuration, wiring, available power capacity and existing system documentation before purchasing.
