Technical specifications, features, applications and purchasing information.
| Brand | Allen-Bradley |
| Model Number | 1766-L32BWA |
| Product Category | PLC Controller |
| Product Family | MicroLogix 1400 |
| Product Bulletin | Bulletin 1766 |
| Controller Type | Programmable Logic Controller |
| Total Embedded Digital I/O | 32 Points |
| Embedded Digital Inputs | 20 Points |
| Fast Digital Inputs | 12 × 24 VDC |
| Standard Digital Inputs | 8 × 24 VDC |
| Digital Input Configuration | 24 VDC Sink/Source |
| Embedded Digital Outputs | 12 Relay Outputs |
| Embedded Analog Inputs | None |
| Embedded Analog Outputs | None |
| Input Power Supply | 120/240 VAC Nominal |
| Power Supply Voltage Range | 100-240 VAC (-15%/+10%) |
| Power Supply Frequency | 47-63 Hz |
| Power Consumption | 120 VA |
| Maximum Power Supply Inrush Current | 25 A for 8 ms at 120 VAC; 40 A for 4 ms at 240 VAC |
| Integrated Sensor Power Supply | 24 VDC, 250 mA Maximum |
| Sensor Supply Capacitive Load | 400 µF Maximum |
| Memory Capacity | 20 KB Total |
| User Program Memory | 10 KB |
| User Data Memory | 10 KB |
| Memory Type | Battery-Backed RAM |
| Data Logging Memory | 128 KB |
| Recipe Storage | Up to 64 KB, Shared with Data Logging Storage |
| Memory Backup Module | Optional |
| High-Speed Digital Inputs | 12 Fast Inputs |
| High-Speed Counter Capability | Up to 6 Channels at 100 kHz |
| Local Expansion I/O | 1762 Expansion Modules |
| Maximum Local Expansion Modules | 7 |
| Ethernet Ports | 1 × RJ45 |
| Ethernet Interface Speed | 10/100 Mbps |
| Ethernet Communication | EtherNet/IP Messaging, Modbus TCP/IP and DNP3 over IP |
| Serial Port 0 | Isolated RS-232/RS-485, 8-Pin Mini-DIN |
| Serial Port 2 | RS-232, 9-Pin D-Sub |
| Supported Serial Protocols | DF1, DH-485, Modbus RTU, ASCII and DNP3 |
| Programming Software | RSLogix 500 or Compatible RSLogix Micro Software |
| Programming Language | Ladder Logic |
| Online Editing | Supported with Compatible Programming Software |
| Embedded LCD | Yes |
| Integrated Keypad | Yes |
| Real-Time Clock | Integrated |
| Digital Trim Potentiometers | 2 |
| PID Control | Supported |
| Embedded Web Server | Supported |
| Mounting Options | DIN Rail or Panel Mounting |
| Enclosure Style | Open-Style Controller |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5-95% Non-Condensing |
| Operating Vibration | 3 g at 10-500 Hz |
| Operating Shock | 30 g |
| Dimensions (W × H × D) | 180 × 90 × 87 mm |
| Product Lifecycle Status | Active Mature |
| Manufacturer Documentation | 1761-SG001 Selection Guide; 1766-IN001 Installation Instructions; 1766-UM001 User Manual |
The Allen-Bradley 1766-L32BWA includes 20 digital inputs and 12 relay outputs. Its inputs consist of 12 fast 24 VDC points and eight standard 24 VDC points, supporting direct connections to compatible industrial sensors, switches and machine control signals.
The controller operates from a nominal 120/240 VAC power supply and includes a separate 24 VDC, 250 mA sensor power output for compatible input devices. The sensor supply is intended for sensors and switches rather than output loads.
The integrated 10/100 Mbps Ethernet interface supports EtherNet/IP messaging, Modbus TCP/IP and DNP3 over IP. Two serial communication ports provide additional flexibility for compatible industrial communication networks and operator interfaces.
The MicroLogix 1400 provides 20 KB of battery-backed RAM, including 10 KB for user programs and 10 KB for user data. Separate data logging and recipe storage capabilities support equipment monitoring and process data handling.
Twelve fast digital inputs support applications involving pulse signals and high-speed counting. The controller can accommodate up to seven compatible Bulletin 1762 expansion I/O modules for applications requiring additional I/O points.
A built-in LCD and keypad support controller status viewing and selected configuration functions. RSLogix 500 programming, online editing, PID instructions and an integrated real-time clock provide useful functionality for machine automation and maintenance.
We support online purchase of the Allen-Bradley 1766-L32BWA PLC Controller. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
What is Allen-Bradley 1766-L32BWA?
Allen-Bradley 1766-L32BWA is a MicroLogix 1400 programmable logic controller with 32 embedded digital I/O points, a nominal 120/240 VAC power supply, an Ethernet communication port and two serial communication ports.
How many inputs and outputs does 1766-L32BWA have?
The controller provides 20 digital inputs and 12 relay outputs. Its inputs include 12 fast 24 VDC points and eight standard 24 VDC points, giving 32 embedded digital I/O points in total.
What supply voltage does 1766-L32BWA require?
The controller uses a nominal 120/240 VAC supply. The manufacturer specifies a 100-240 VAC input range with -15%/+10% tolerance at 47-63 Hz. It also provides a separate 24 VDC sensor supply rated at 250 mA maximum.
Does 1766-L32BWA have analog inputs or outputs?
No. The 1766-L32BWA does not include embedded analog I/O. The related 1766-L32BWAA version adds four voltage analog inputs and two voltage analog outputs, so the complete catalog number must be checked when analog signals are required.
How much memory does 1766-L32BWA provide?
The controller has 20 KB of battery-backed RAM, divided into 10 KB user program memory and 10 KB user data memory. It also provides 128 KB for data logging, with recipe storage using part of that memory.
What communication ports are available on 1766-L32BWA?
The controller provides one 10/100 Mbps Ethernet RJ45 port, one isolated RS-232/RS-485 port with an eight-pin Mini-DIN connection, and one RS-232 port with a nine-pin D-Sub connection.
Does 1766-L32BWA support EtherNet/IP and Modbus TCP/IP?
Yes. The Ethernet interface supports EtherNet/IP messaging, Modbus TCP/IP and DNP3 over IP. EtherNet/IP messaging support should not be confused with full EtherNet/IP implicit I/O scanning capabilities.
Can 1766-L32BWA be expanded with additional I/O modules?
Yes. The MicroLogix 1400 supports up to seven compatible Bulletin 1762 expansion I/O modules. Selection of expansion modules must consider the controller's power budget and supported module configurations.
What is the difference between 1766-L32BWA and 1766-L32AWA?
The 1766-L32BWA has 20 digital 24 VDC inputs and 12 relay outputs, while the 1766-L32AWA has 20 digital 120 VAC inputs and 12 relay outputs. Both use a nominal 120/240 VAC power supply, but their input circuits are not interchangeable.
What software is used to program 1766-L32BWA?
The controller is programmed using compatible versions of RSLogix 500 or RSLogix Micro software. It uses ladder logic and supports online editing when the software version and controller firmware are compatible.
Does 1766-L32BWA have a built-in LCD and high-speed counters?
Yes. The MicroLogix 1400 includes an LCD and keypad for local monitoring and supported configuration functions. Its 12 fast digital inputs can be used in high-speed counter applications, with up to six high-speed counter channels rated at 100 kHz.
What should be checked before ordering 1766-L32BWA?
Verify the exact catalog number 1766-L32BWA, hardware series and firmware revision, 120/240 VAC power supply, 20 digital 24 VDC input points, 12 relay output points, 20 KB memory capacity, Ethernet and serial communication settings, 1762 expansion module compatibility, program backup, battery condition, open-style enclosure requirements and 180 × 90 × 87 mm controller dimensions before replacing an existing PLC.
