| Brand | Allen-Bradley |
| Model Number | 1746-A10 |
| Product Category | PLC Chassis |
| Product Family | SLC 500 |
| Product Bulletin | Bulletin 1746 |
| Manufacturer Product Description | 1746 SLC System, 10-Slot Chassis, Modular Hardware Style |
| Chassis Type | Modular PLC Chassis |
| Number of Module Slots | 10 |
| Module Interface | SLC 500 / Bulletin 1746 Backplane |
| Compatible Controller Platform | SLC 500 Modular Control System |
| Compatible Module Types | Selected SLC 500 Processors, I/O Adapters and Bulletin 1746 I/O Modules |
| Processor or I/O Adapter Position | Leftmost Module Slot of the Primary Chassis |
| Power Supply Configuration | Separately Selected Compatible SLC 500 Power Supply |
| Power Supply Mounting Location | Dedicated Left-Side Chassis Mounting Position |
| Power Distribution Method | Chassis Backplane Powered by Compatible External Chassis Power Supply |
| Maximum Interconnected Chassis | 3 |
| Maximum Module Slots with Three 10-Slot Chassis | 30, Subject to Controller and System Configuration |
| Compatible Chassis Interconnect Cable | 1746-C7, 0.15 m (0.5 ft) |
| Additional Interconnect Cable | 1746-C9, 0.91 m (3 ft) |
| Additional Interconnect Cable Option | 1746-C16, 1.22 m (4 ft) |
| Compatible Unused Slot Filler | 1746-N2 |
| Mounting Method | Back-Panel Mounting |
| Mounting Tab Quantity | 6 |
| Mounting Hardware | M4 or M5 Screws with Appropriate Grounding Hardware, per Installation Instructions |
| Cooling Method | Convection |
| Dimensions (H × W × D) | 171 × 397 × 145 mm |
| Dimensions in Inches (H × W × D) | 6.73 × 15.64 × 5.71 in |
| Approximate Weight | 1.5 kg (3.3 lb), Without Installed Modules |
| Operating Temperature Range | 0°C to +60°C (32°F to 140°F) |
| Enclosure Requirements | Suitable Industrial Enclosure with Required Grounding and Ventilation Clearances |
| Product Lifecycle Status | Discontinued |
| Discontinuation Date | March 31, 2024 |
| Manufacturer Replacement Classification | No Planned Rockwell Automation Replacement |
| Manufacturer UPC | 662468302845 |
| Manufacturer Documentation | 1746-IN016 SLC 500 Modular Chassis Installation Instructions |
The Allen-Bradley 1746-A10 provides ten module positions for compatible SLC 500 processors, communication adapters and Bulletin 1746 I/O modules. The modular design supports flexible configuration of industrial automation control systems according to application requirements.
The chassis incorporates the SLC 500 backplane, providing electrical connections and communication paths between compatible installed modules. A separately selected SLC 500 power supply distributes operating power through the chassis assembly.
Compatible SLC 500 modular chassis can be interconnected using specified 1746-C7, 1746-C9 or 1746-C16 interconnect cables. A supported three-chassis arrangement can provide up to 30 module positions, subject to the controller architecture and power requirements.
The chassis provides a dedicated mounting position for a compatible SLC 500 power supply on its left side, outside the ten module slots. This arrangement allows the chassis to accommodate processor and I/O modules without occupying a module slot for the power supply.
The 1746-A10 uses six mounting tabs for installation on a suitable industrial enclosure back panel. Its dimensions are 171 × 397 × 145 mm, with manufacturer installation instructions covering mechanical mounting, grounding and required installation clearances.
The chassis provides a replacement option for compatible existing SLC 500 installations. Although the 1746-A10 was discontinued in March 2024, its standardized modular configuration remains relevant to maintenance projects where installed Bulletin 1746 equipment must be retained.
We support online purchase of the Allen-Bradley 1746-A10 PLC Chassis. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
What is Allen-Bradley 1746-A10?
Allen-Bradley 1746-A10 is a Bulletin 1746 ten-slot modular chassis designed for the SLC 500 PLC system. It provides mechanical support, backplane power distribution and electrical connections for compatible processors, adapters and I/O modules.
How many module slots does 1746-A10 provide?
The 1746-A10 provides ten module slots. In a primary modular SLC 500 chassis, the processor or I/O adapter is normally installed in the leftmost module position, with compatible I/O and communication modules installed in the remaining positions according to the system configuration.
Does 1746-A10 include a PLC processor?
No. The 1746-A10 is a chassis assembly rather than a complete PLC controller. A compatible SLC 500 processor or I/O adapter must be selected separately, together with the required I/O modules and system power supply.
Does 1746-A10 include a power supply?
No. The chassis is designed to operate with a separately selected compatible SLC 500 power supply mounted on the left side of the assembly. Power supply selection must account for the total 5 VDC and 24 VDC current requirements of the installed modules.
Can multiple 1746-A10 chassis be connected?
Yes. Rockwell Automation documents configurations with up to three interconnected SLC 500 modular chassis. Three ten-slot chassis can provide a total of 30 module slots, subject to the processor or adapter requirements, interconnect cabling and applicable system limitations.
Which interconnect cables are compatible with 1746-A10?
Rockwell Automation lists the 1746-C7 cable at 0.15 m, 1746-C9 at 0.91 m and 1746-C16 at 1.22 m for compatible modular chassis interconnections. The correct cable depends on chassis positioning and the installation requirements.
What are the dimensions of 1746-A10?
The published chassis dimensions are 171 mm high, 397 mm wide and 145 mm deep, equivalent to approximately 6.73 × 15.64 × 5.71 inches. Additional installation clearance is necessary for ventilation, wiring and access.
How much does the Allen-Bradley 1746-A10 chassis weigh?
The published approximate chassis weight is 1.5 kg, or 3.3 lb, without installed modules. The assembled equipment weight increases when the processor, I/O modules, power supply and other accessories are installed.
How is 1746-A10 mounted?
The chassis is mounted on an industrial enclosure back panel using six mounting tabs. Rockwell Automation specifies suitable M4 or M5 mounting hardware and grounding arrangements in the modular chassis installation instructions. It is not a standard DIN rail-mounted chassis.
What is the difference between 1746-A10 and 1746-A7?
The 1746-A10 provides ten module slots and measures approximately 171 × 397 × 145 mm, while the 1746-A7 provides seven module slots and measures approximately 171 × 282 × 145 mm. Both belong to the modular SLC 500 chassis family, but the different widths and slot capacities must be considered when replacing or expanding an installation.
Is Allen-Bradley 1746-A10 discontinued?
Yes. Rockwell Automation lists the 1746-A10 as discontinued effective March 31, 2024, with no planned Rockwell Automation replacement. Maintenance or system modernization should therefore consider the compatibility of the existing SLC 500 architecture and any proposed alternative platform.
What should be checked before ordering 1746-A10?
Verify the exact catalog number 1746-A10, chassis hardware series, ten-slot capacity, existing SLC 500 processor or adapter, required Bulletin 1746 I/O modules, power supply compatibility, total backplane power budget, available enclosure space, 171 × 397 × 145 mm dimensions, six mounting points, grounding requirements and any 1746-C series chassis interconnect cables. If replacing an installed chassis, confirm the PLC program backup, module slot arrangement and existing wiring before removing equipment.
Send us your part number and technical requirements.
Explore more industrial components from our catalog.
Available in stock (400)
| Brand | Allen-Bradley |
| Model Number | 1746-A10 |
| Product Category | PLC Chassis |
| Product Family | SLC 500 |
| Product Bulletin | Bulletin 1746 |
| Manufacturer Product Description | 1746 SLC System, 10-Slot Chassis, Modular Hardware Style |
| Chassis Type | Modular PLC Chassis |
| Number of Module Slots | 10 |
| Module Interface | SLC 500 / Bulletin 1746 Backplane |
| Compatible Controller Platform | SLC 500 Modular Control System |
| Compatible Module Types | Selected SLC 500 Processors, I/O Adapters and Bulletin 1746 I/O Modules |
| Processor or I/O Adapter Position | Leftmost Module Slot of the Primary Chassis |
| Power Supply Configuration | Separately Selected Compatible SLC 500 Power Supply |
| Power Supply Mounting Location | Dedicated Left-Side Chassis Mounting Position |
| Power Distribution Method | Chassis Backplane Powered by Compatible External Chassis Power Supply |
| Maximum Interconnected Chassis | 3 |
| Maximum Module Slots with Three 10-Slot Chassis | 30, Subject to Controller and System Configuration |
| Compatible Chassis Interconnect Cable | 1746-C7, 0.15 m (0.5 ft) |
| Additional Interconnect Cable | 1746-C9, 0.91 m (3 ft) |
| Additional Interconnect Cable Option | 1746-C16, 1.22 m (4 ft) |
| Compatible Unused Slot Filler | 1746-N2 |
| Mounting Method | Back-Panel Mounting |
| Mounting Tab Quantity | 6 |
| Mounting Hardware | M4 or M5 Screws with Appropriate Grounding Hardware, per Installation Instructions |
| Cooling Method | Convection |
| Dimensions (H × W × D) | 171 × 397 × 145 mm |
| Dimensions in Inches (H × W × D) | 6.73 × 15.64 × 5.71 in |
| Approximate Weight | 1.5 kg (3.3 lb), Without Installed Modules |
| Operating Temperature Range | 0°C to +60°C (32°F to 140°F) |
| Enclosure Requirements | Suitable Industrial Enclosure with Required Grounding and Ventilation Clearances |
| Product Lifecycle Status | Discontinued |
| Discontinuation Date | March 31, 2024 |
| Manufacturer Replacement Classification | No Planned Rockwell Automation Replacement |
| Manufacturer UPC | 662468302845 |
| Manufacturer Documentation | 1746-IN016 SLC 500 Modular Chassis Installation Instructions |
The Allen-Bradley 1746-A10 provides ten module positions for compatible SLC 500 processors, communication adapters and Bulletin 1746 I/O modules. The modular design supports flexible configuration of industrial automation control systems according to application requirements.
The chassis incorporates the SLC 500 backplane, providing electrical connections and communication paths between compatible installed modules. A separately selected SLC 500 power supply distributes operating power through the chassis assembly.
Compatible SLC 500 modular chassis can be interconnected using specified 1746-C7, 1746-C9 or 1746-C16 interconnect cables. A supported three-chassis arrangement can provide up to 30 module positions, subject to the controller architecture and power requirements.
The chassis provides a dedicated mounting position for a compatible SLC 500 power supply on its left side, outside the ten module slots. This arrangement allows the chassis to accommodate processor and I/O modules without occupying a module slot for the power supply.
The 1746-A10 uses six mounting tabs for installation on a suitable industrial enclosure back panel. Its dimensions are 171 × 397 × 145 mm, with manufacturer installation instructions covering mechanical mounting, grounding and required installation clearances.
The chassis provides a replacement option for compatible existing SLC 500 installations. Although the 1746-A10 was discontinued in March 2024, its standardized modular configuration remains relevant to maintenance projects where installed Bulletin 1746 equipment must be retained.
We support online purchase of the Allen-Bradley 1746-A10 PLC Chassis. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
What is Allen-Bradley 1746-A10?
Allen-Bradley 1746-A10 is a Bulletin 1746 ten-slot modular chassis designed for the SLC 500 PLC system. It provides mechanical support, backplane power distribution and electrical connections for compatible processors, adapters and I/O modules.
How many module slots does 1746-A10 provide?
The 1746-A10 provides ten module slots. In a primary modular SLC 500 chassis, the processor or I/O adapter is normally installed in the leftmost module position, with compatible I/O and communication modules installed in the remaining positions according to the system configuration.
Does 1746-A10 include a PLC processor?
No. The 1746-A10 is a chassis assembly rather than a complete PLC controller. A compatible SLC 500 processor or I/O adapter must be selected separately, together with the required I/O modules and system power supply.
Does 1746-A10 include a power supply?
No. The chassis is designed to operate with a separately selected compatible SLC 500 power supply mounted on the left side of the assembly. Power supply selection must account for the total 5 VDC and 24 VDC current requirements of the installed modules.
Can multiple 1746-A10 chassis be connected?
Yes. Rockwell Automation documents configurations with up to three interconnected SLC 500 modular chassis. Three ten-slot chassis can provide a total of 30 module slots, subject to the processor or adapter requirements, interconnect cabling and applicable system limitations.
Which interconnect cables are compatible with 1746-A10?
Rockwell Automation lists the 1746-C7 cable at 0.15 m, 1746-C9 at 0.91 m and 1746-C16 at 1.22 m for compatible modular chassis interconnections. The correct cable depends on chassis positioning and the installation requirements.
What are the dimensions of 1746-A10?
The published chassis dimensions are 171 mm high, 397 mm wide and 145 mm deep, equivalent to approximately 6.73 × 15.64 × 5.71 inches. Additional installation clearance is necessary for ventilation, wiring and access.
How much does the Allen-Bradley 1746-A10 chassis weigh?
The published approximate chassis weight is 1.5 kg, or 3.3 lb, without installed modules. The assembled equipment weight increases when the processor, I/O modules, power supply and other accessories are installed.
How is 1746-A10 mounted?
The chassis is mounted on an industrial enclosure back panel using six mounting tabs. Rockwell Automation specifies suitable M4 or M5 mounting hardware and grounding arrangements in the modular chassis installation instructions. It is not a standard DIN rail-mounted chassis.
What is the difference between 1746-A10 and 1746-A7?
The 1746-A10 provides ten module slots and measures approximately 171 × 397 × 145 mm, while the 1746-A7 provides seven module slots and measures approximately 171 × 282 × 145 mm. Both belong to the modular SLC 500 chassis family, but the different widths and slot capacities must be considered when replacing or expanding an installation.
Is Allen-Bradley 1746-A10 discontinued?
Yes. Rockwell Automation lists the 1746-A10 as discontinued effective March 31, 2024, with no planned Rockwell Automation replacement. Maintenance or system modernization should therefore consider the compatibility of the existing SLC 500 architecture and any proposed alternative platform.
What should be checked before ordering 1746-A10?
Verify the exact catalog number 1746-A10, chassis hardware series, ten-slot capacity, existing SLC 500 processor or adapter, required Bulletin 1746 I/O modules, power supply compatibility, total backplane power budget, available enclosure space, 171 × 397 × 145 mm dimensions, six mounting points, grounding requirements and any 1746-C series chassis interconnect cables. If replacing an installed chassis, confirm the PLC program backup, module slot arrangement and existing wiring before removing equipment.
