Technical specifications, features, applications and purchasing information.
| Brand | Allen-Bradley |
| Model Number | 150-C108NBD |
| Product Category | Soft Starter |
| Product Family | SMC-3 |
| Product Bulletin | Bulletin 150-C |
| Controller Type | Solid-State Smart Motor Controller |
| Rated Controller Current | 108 A |
| Nominal Main Power Voltage | 480 VAC |
| Main Power Voltage Class | 200-480 VAC |
| Power Circuit | Three-Phase, 3-Wire |
| Operating Frequency | 50/60 Hz |
| Control Supply Voltage | 100-240 VAC |
| Starting Duty | 350% of Motor Full-Load Current |
| Line-Connected Motor Current Range | 27-108 A at 380/400/415/460 VAC |
| Inside-Delta Motor Current Range | 47-187 A at 380/400/415/460 VAC |
| Maximum Line-Connected Motor Power at 400/415VAC | 55 kW at 50 Hz |
| Line-Connected Motor Power at 460VAC | 50-75 HP at 60 Hz |
| Maximum Inside-Delta Motor Power at 400/415VAC | 90 kW at 50 Hz |
| Inside-Delta Motor Power at 460VAC | 40-150 HP at 60 Hz |
| Rated Control Current During Start with Fan | 200 mA at 120 VAC; 120 mA at 240 VAC |
| Fan Power Rating | 20 VA |
| Minimum Control Input ON-State Voltage | 85 VAC |
| Control Input ON-State Current | 9.8 mA at 120 VAC; 19.6 mA at 240 VAC |
| Selectable Current Limit | 150%, 250%, 350% and 450% of Motor Full-Load Current |
| Selectable Start Times | 2, 5, 10, 15, 20, 25 and 30 Seconds |
| Selectable Initial Torque | 15%, 25%, 35% and 65% of Locked-Rotor Torque |
| Selectable Kick Start Duration | Off, 0.5, 1.0 or 1.5 Seconds at 450% FLA |
| Soft Stop Configuration | Off, 100%, 200% or 300% of Selected Start Time When Wired |
| Integrated Motor Overload Protection | Yes |
| Selectable Overload Trip Classes | Class 10, 15 and 20 |
| Internal Bypass | Integrated |
| Motor Rotation Control | Single Direction |
| Auxiliary Overload/Fault Contact | 1 Normally Open Contact at Terminals 97-98 |
| Auxiliary Contact Conventional Thermal Current | 1 A |
| Auxiliary Contact Operational Rating | 0.6 A at 120 VAC; 0.3 A at 240 VAC |
| Auxiliary Contact Make Capacity | 432 VA |
| Auxiliary Contact Break Capacity | 72 VA |
| Integrated Display | No |
| Enclosure Configuration | Open Type |
| Degree of Protection | IP2X |
| Rated Insulation Voltage | 600 VAC per UL/CSA/NEMA |
| Rated Impulse Withstand Voltage | 6 kV |
| Power Circuit Dielectric Withstand | 2500 VAC per IEC |
| Power Circuit dV/dt Protection | 1000 V/µs |
| Short-Circuit Protection Device Performance | Type 1 |
| Maximum High-Capacity Available Fault Current | 70 kA at 600 V with Specified Protective Devices and Connection Conditions |
| Operating Temperature | -5°C to 50°C |
| Relative Humidity | 5-95% Non-Condensing |
| Maximum Installation Altitude | 2000 m |
| Pollution Degree | 2 |
| Steady-State Heat Dissipation | 62 W |
| Control Terminal Conductor Size | 0.2-2.5 mm² |
| Control Terminal Tightening Torque | 0.45-0.9 Nm |
| Power Terminal Connection | One M10 × 1.5 Hole per Power Pole |
| Mounting Hole Diameter | 7.5 mm |
| Dimensions (H × W × D) | 443.7 × 196.4 × 205.2 mm |
| Weight | 15 kg |
| Product Lifecycle Status | Active |
The Allen-Bradley SMC-3 150-C108NBD provides a 108 A controller rating for compatible three-phase induction motors. The documented line-connected motor current range is 27-108 A at 380/400/415/460 VAC, with motor ratings of 50-75 HP at 460 VAC.
The controller operates with a 100-240 VAC control supply and a nominal 480 VAC three-phase power circuit. This configuration is intended for compatible industrial motor control systems and differs from the 24 V AC/DC control version.
The internal bypass reduces thyristor conduction losses after the motor reaches its operating condition. The manufacturer specifies 62 W steady-state heat dissipation for this model.
Selectable current limits of 150-450% of motor full-load current, start times from 2 to 30 seconds, adjustable initial torque and configurable soft stopping help adapt motor acceleration and deceleration to compatible mechanical loads.
Electronic motor overload protection includes selectable Class 10, 15 and 20 trip characteristics. A normally open overload/fault auxiliary contact supports compatible monitoring and control circuits.
The open-type IP2X controller measures 443.7 × 196.4 × 205.2 mm and weighs 15 kg. It supports line-connected and inside-delta motor installations when correctly selected and wired.
We support online purchase of the Allen-Bradley 150-C108NBD Soft Starter. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
What is Allen-Bradley 150-C108NBD?
Allen-Bradley 150-C108NBD is a Bulletin 150-C SMC-3 solid-state smart motor controller rated at 108 A, designed for compatible three-phase induction motors with a nominal 480 VAC main power circuit and 100-240 VAC control supply.
What is the rated current of 150-C108NBD?
The controller has a 108 A current rating. Rockwell Automation specifies a line-connected motor current range of 27-108 A for supported 380/400/415/460 VAC applications.
What control voltage does 150-C108NBD require?
This model uses 100-240 VAC control power. The manufacturer's specified control current during starting with the fan operating is 200 mA at 120 VAC or 120 mA at 240 VAC.
What is the difference between 150-C108NBD and 150-C108NBR?
The 150-C108NBD uses a 100-240 VAC control supply, while the 150-C108NBR uses 24 V AC/DC control power. These configurations must not be interchanged without checking the control supply and fan power requirements.
What motor horsepower range does 150-C108NBD support?
Manufacturer selection data identifies a 50-75 HP range for line-connected motors at 460 VAC. Motor full-load current, starting duty and installation requirements must also be considered.
Does 150-C108NBD support inside-delta motor connections?
Yes. Rockwell Automation specifies an inside-delta motor current range of 47-187 A for compatible 380/400/415/460 VAC installations. Wiring and protective device selection must follow the installation instructions.
Does 150-C108NBD include an internal bypass?
Yes. The controller includes an integrated bypass to reduce power losses and heat generation during the applicable full-speed motor running condition.
What starting current limits are available?
The selectable current limits are 150%, 250%, 350% and 450% of motor full-load current. The controller also provides configurable starting times, initial torque and kick-start settings.
Does 150-C108NBD include electronic motor overload protection?
Yes. Integrated motor overload protection supports Class 10, 15 and 20 trip settings. The selected protection settings must be appropriate for the connected motor and operating duty.
Can 150-C108NBD perform soft stopping?
Yes. Soft stopping can be disabled or configured to 100%, 200% or 300% of the selected starting time when the starter is properly wired and configured.
Does 150-C108NBD have an integrated display or fault contact?
The controller does not include an integrated display. It provides one normally open overload/fault auxiliary contact at terminals 97-98, with operational ratings of 0.6 A at 120 VAC or 0.3 A at 240 VAC.
What should be checked before ordering 150-C108NBD?
Verify the exact catalog number 150-C108NBD, 108 A controller rating, nominal 480 VAC three-phase main supply, 100-240 VAC control voltage, motor full-load current, line or inside-delta wiring, overload trip class, starting duty, fan power requirements, fault contact connections, protective devices, IP2X construction and 443.7 × 196.4 × 205.2 mm installation dimensions.
