Rotation Monitoring
The XSAV12801 is an inductive proximity sensor designed for rotation-monitoring applications with an adjustable frequency range of 120 to 3000 impulses per minute.
Schneider XSAV12801 Inductive Sensor M30 10mm 24-240VAC
Available in stock (200)
Regular price
$17.28
Sale price
Regular price
Shipping calculated at checkout.
Technical Specifications
| Brand | Schneider |
| Model Number | XSAV12801 |
| Product Category | Inductive Sensor |
| Sensor Type | Inductive Proximity Sensor |
| Sensor Name | XSA |
| Device Application | Rotation Monitoring |
| Sensor Design | Cylindrical M30 |
| Thread Type | M30 x 1.5 |
| Nominal Sensing Distance | 10 mm |
| Sensing Range | 8-15 mm |
| Adjustable Frequency Range | 120-3000 impulses/min |
| Wiring Technique | 2-Wire |
| Discrete Output Function | 1 NC |
| Output Circuit Type | AC/DC |
| Rated Supply Voltage | 24-210 VDC / 24-240 VAC 50/60 Hz |
| Switching Capacity | 5-200 mA DC / 5-350 mA AC |
| Electrical Connection | Cable |
| Cable Length | 2 m |
| Mounting | Flush Mountable |
| Enclosure Material | Nickel-Plated Brass |
| Protection Rating | IP67 |
| Switching Frequency | 800 Hz max. |
| Status Indicator | 1 Red LED for Output State |
Key Features
M30 Cylindrical Design
The sensor uses a cylindrical M30 body with an M30 x 1.5 thread and supports flush mounting.
10mm Nominal Sensing Distance
The documented nominal sensing distance is 10 mm, with a specified sensing range of 8 to 15 mm.
24-240VAC / 24-210VDC
The two-wire AC/DC sensor supports 24 to 240 VAC at 50/60 Hz and 24 to 210 VDC supply ranges.
1NC Discrete Output
The documented output configuration is a two-wire discrete circuit with one normally closed output function.
2m Pre-Cabled Connection
The XSAV12801 uses a pre-cabled electrical connection with a documented cable length of 2 m.
Applications
- Industrial rotation monitoring
- Shaft rotation detection
- Conveyor motion monitoring
- Slip detection systems
- Shaft overload monitoring
- Industrial machine motion detection
- Material handling equipment monitoring
- Factory automation sensing systems
Purchase Information
We support online purchase of the Schneider XSAV12801 Inductive Sensor. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
Frequently Asked Questions
What is Schneider XSAV12801?
Schneider XSAV12801 is an M30 cylindrical inductive proximity sensor designed for rotation monitoring.
What is the nominal sensing distance of XSAV12801?
The documented nominal sensing distance is 10 mm.
What sensing range does XSAV12801 have?
The documented sensing range is 8 to 15 mm.
What rotation-monitoring frequency range does XSAV12801 support?
The documented adjustable frequency range is 120 to 3000 impulses per minute.
What supply voltage does XSAV12801 use?
The documented supply range is 24 to 210 VDC or 24 to 240 VAC at 50/60 Hz.
What output configuration does XSAV12801 use?
The sensor uses a two-wire AC/DC output circuit with one normally closed discrete output.
What switching capacity is specified for XSAV12801?
The documented switching capacity is 5 to 200 mA DC and 5 to 350 mA AC.
What electrical connection does XSAV12801 use?
The sensor has a pre-cabled connection with a documented cable length of 2 m.
Can XSAV12801 be flush mounted?
Yes. The documented sensor configuration is flush mountable in metal.
What protection rating does XSAV12801 have?
The documented degree of protection is IP67 according to IEC 60529.
What applications can XSAV12801 be considered for?
It can be considered for rotation monitoring, shaft motion detection, slip detection and related industrial motion-monitoring applications after the sensing distance, frequency range, electrical supply and installation requirements have been checked.
What should be checked before ordering XSAV12801?
Check the complete model number, M30 mounting requirement, 10 mm nominal sensing distance, 120 to 3000 impulses per minute range, AC/DC supply, 1 NC output configuration, 2 m cable and machine sensing requirements before ordering.
