20 I/O Compact Smart Relay
Provides 12 digital inputs, 2 analog inputs, and 8 relay outputs in a compact Zelio Logic format for small automation control tasks.
1 / 2
Schneider
Schneider SR2A201BD Safety Relay 24VAC/DC 2 Safety Outputs
PRODUCT PRICE
USD
$136.48
Available to order
Request a QuoteNeed multiple units or help confirming a model? Contact our team.
Payments
Available payment methods
Shop with confidence
Bulk orders & part matching
Contact our team for quantity requests and help confirming your part number.
Service Guarantee
PRODUCT DOCUMENTATION
Product Information
Technical specifications, features, applications and purchasing information.
Technical Specifications
| Brand | Schneider |
| Model Number | SR2A201BD |
| Product Category | Safety Relay |
| Product Family | Zelio Logic SR2 SR3 |
| Product Type | Compact Smart Relay |
| Total I/O | 20 |
| Number of Digital Inputs | 12 (IEC 61131-2) |
| Number of Analog Inputs | 2 |
| Number of Relay Outputs | 8 |
| Rated Supply Voltage | 24 V DC |
| Display | Yes, with local display |
| Clock | No |
| Backup Time | 10 years at 25°C |
| Mounting | 35 mm DIN Rail |
| Net Weight | 0.38 kg |
Key Features
24 V DC Supply
Operates on a 24 V DC rated supply voltage, suitable for low-voltage control panel applications.
Integrated Display
Includes a local display for monitoring and parameter access without additional programming tools.
Relay Outputs
Eight relay outputs support switching of various loads in industrial control circuits.
DIN Rail Mounting
Designed for mounting on standard 35 mm DIN rail for efficient panel installation.
Applications
- Small machine control logic
- Lighting and building automation
- Pumping and HVAC control panels
- Conveyor and material handling logic
- Packaging equipment control
- Industrial process interlocking
Purchase Information
We support online purchase of the Schneider SR2A201BD Safety Relay. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
Frequently Asked Questions
What is the Schneider SR2A201BD? The SR2A201BD is a compact smart relay from the Zelio Logic SR2 SR3 range with 20 I/O and a 24 V DC supply.
How many inputs and outputs does it have? It provides 12 digital inputs, 2 analog inputs, and 8 relay outputs.
What is the supply voltage? The rated supply voltage is 24 V DC.
Does it have a display? Yes, this model includes a local display.
Does it include a clock? No, this model does not include a clock function.
How is it mounted? It is designed for mounting on 35 mm DIN rail.
What is the backup time? The backup time is specified as 10 years at 25°C.
What is the net weight? The net weight is approximately 0.38 kg.
What should be checked before ordering? Verify the complete catalog number, I/O count, supply voltage, output type, and panel space requirements against your application.
