380-460VAC Supply
The drive is specified for a three-phase 380-460 VAC supply.
Schneider ATV310HU75N4E Variable Frequency Drive 7.5kW 380-460V 3 Phase
Available in stock (400)
Regular price
$258.86
Sale price
Regular price
Shipping calculated at checkout.
Technical Specifications
| Brand | Schneider |
| Model Number | ATV310HU75N4E |
| Product Category | Variable Frequency Drive |
| Product Family | Easy Altivar 310 |
| Product Type | Variable Speed Drive |
| Rated Supply Voltage | 380-460 VAC |
| Network Phases | 3 Phase |
| Motor Power - Heavy Duty | 7.5 kW / 10 hp |
| Motor Power - Normal Duty | 11 kW / 15 hp |
| Supply Frequency | 50/60 Hz ±5% |
| Motor Type | Three-Phase Asynchronous Motor |
| Control | U/F and Sensorless Vector Control |
| EMC Filter | Without EMC Filter |
| Communication Protocol | Modbus |
| Communication Interface | 2-Wire RS-485 |
| Communication Connector | RJ45 |
| Protection Rating | IP20 |
| Operating Temperature | -10°C to +55°C |
| Output Frequency | 0.5-400 Hz |
Key Features
7.5kW Heavy Duty
The documented heavy-duty motor power rating is 7.5 kW / 10 hp.
11kW Normal Duty
The documented normal-duty motor power rating is 11 kW / 15 hp.
Sensorless Vector Control
The drive incorporates U/F and sensorless vector motor control functions.
Modbus Communication
Modbus communication is provided through a 2-wire RS-485 physical interface.
0.5-400Hz Output
The documented output frequency range is 0.5-400 Hz.
Applications
- Three-phase asynchronous motor speed control
- Industrial machine drive systems
- Material handling machinery
- Packaging machinery
- Printing machinery
- Machine tool applications
- Textile machinery
- Woodworking machinery
Purchase Information
We support online purchase of the Schneider ATV310HU75N4E Variable Frequency Drive. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
Frequently Asked Questions
What is Schneider ATV310HU75N4E?
Schneider ATV310HU75N4E is an Easy Altivar 310 variable speed drive for three-phase asynchronous motors.
What supply voltage does ATV310HU75N4E use?
The documented rated supply voltage is 380-460 VAC, three phase.
What motor power is specified for heavy-duty operation?
The documented heavy-duty motor power rating is 7.5 kW / 10 hp.
What motor power is specified for normal-duty operation?
The documented normal-duty motor power rating is 11 kW / 15 hp.
What supply frequency does ATV310HU75N4E support?
The documented supply frequency is 50/60 Hz ±5%.
What motor control methods are provided?
Schneider product information identifies U/F and sensorless vector control.
Does ATV310HU75N4E support Modbus communication?
Yes. The documented communication protocol is Modbus using a 2-wire RS-485 physical interface.
What is the output frequency range?
The documented output frequency range is 0.5-400 Hz.
What protection rating is specified?
The documented protection rating is IP20.
What is the documented operating temperature range?
The documented operating temperature range is -10°C to +55°C.
What applications can ATV310HU75N4E be considered for?
It can be considered for asynchronous motor control in industrial machinery, including material handling, packaging, printing, textile, woodworking and machine tool applications, subject to system requirements.
What should be checked before ordering ATV310HU75N4E?
Check the complete model number, supply voltage, motor power and duty requirements, control requirements, communication requirements, environmental conditions and installation requirements against the intended system.
