DPST-NO Contact
Provides two normally open contacts for safety circuit applications.
Omron D4DS-K3 Safety Door Switch 230VAC 2A Key
Available in stock (400)
Regular price
$15.44
Sale price
Regular price
Shipping calculated at checkout.
Technical Specifications
| Brand | Omron |
| Model Number | D4DS-K3 |
| Product Category | Safety Door Switch |
| Product Family | D4DS |
| Type | Key Operation Safety Door Switch |
| Contact Configuration | DPST-NO |
| Contact Material | Gold-clad silver |
| Rated Voltage | 250 VAC |
| Rated Current | 2 A |
| Protection Rating | IP67 |
| Operating Temperature | -40°C to +80°C |
Key Features
2 A Rated Current
Rated for 2 A at 250 VAC for reliable switching in industrial control systems.
Key Operation
Designed for key-operated safety door switching with a robust mechanical actuation mechanism.
IP67 Protection
IP67 protection rating indicates resistance to dust and temporary immersion in water.
Wide Temperature Range
Operating temperature range from -40°C to +80°C for demanding industrial environments.
D4DS Series
Part of the Omron D4DS product family of safety door switches.
Applications
- Industrial machinery safety door monitoring
- Machine guard interlock systems
- Automated production line safety circuits
- Equipment access point protection
- Safety interlock for robotic workcells
- Packaging machinery safety applications
- Material handling equipment safety
- Industrial automation safety system integration
Purchase Information
We support online purchase of the Omron D4DS-K3 Safety Door Switch. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
Frequently Asked Questions
What is Omron D4DS-K3?
Omron D4DS-K3 is a key-operated safety door switch from the D4DS product family.
What type of product is D4DS-K3?
It is a safety door switch designed for interlock applications in industrial machinery and safety circuits.
What is the contact configuration of D4DS-K3?
Omron documentation identifies DPST-NO (Double Pole Single Throw - Normally Open) contact configuration.
What is the rated voltage and current for D4DS-K3?
Published specifications list 250 VAC and 2 A as the rated voltage and current.
What protection rating does D4DS-K3 have?
Omron product information specifies an IP67 protection rating for the D4DS-K3.
What is the operating temperature range of D4DS-K3?
The documented operating temperature range is -40°C to +80°C.
What contact material is used in D4DS-K3?
Omron documentation identifies gold-clad silver as the contact material.
What applications can D4DS-K3 be used for?
It can be considered for safety door monitoring, machine guard interlocking, and other industrial safety circuit applications after verifying compatibility with the specific machinery and safety system requirements.
What should be checked before ordering D4DS-K3?
Verify the complete model number, contact configuration, rated voltage and current, IP rating, operating temperature range, and mounting and wiring requirements against the specific application.
