230VAC Operation
The fan operates on a 230 VAC power supply, suitable for standard industrial AC voltage systems.
Ebmpapst W2S130-AA03-77 AC Axial Fan 230VAC 190/205W
Available in stock (200)
Regular price
$57.44
Sale price
Regular price
Shipping calculated at checkout.
Technical Specifications
| Brand | Ebmpapst |
| Model Number | W2S130-AA03-77 |
| Product Category | AC Axial Fan |
| Fan Type | Axial Fan |
| Rated Voltage | 230 VAC |
| Power Input | 190/205 W |
| Rated Frequency | 50/60 Hz |
| Speed | 2600/3000 RPM |
| Air Flow | 350/410 CFM |
| Diameter | 130 mm |
| Protection Rating | IP44 |
Key Features
190/205W Power Input
Power consumption is specified as 190 W at 50 Hz and 205 W at 60 Hz for the respective operating frequencies.
130mm Diameter
The fan has a 130 mm diameter, providing a compact footprint for installations where space is a consideration.
350/410 CFM Airflow
Airflow is documented as 350 CFM at 50 Hz and 410 CFM at 60 Hz, supporting various ventilation and cooling requirements.
2600/3000 RPM Speed
The fan speed is specified at 2600 RPM for 50 Hz operation and 3000 RPM for 60 Hz operation.
IP44 Protection Rating
The fan carries an IP44 protection rating, providing protection against solid objects larger than 1mm and splashing water.
Applications
- Industrial equipment cooling
- Electrical cabinet ventilation
- HVAC system air circulation
- Industrial machinery ventilation
- Control cabinet cooling
- Power supply unit cooling
- Industrial automation system ventilation
- General industrial air movement
Purchase Information
We support online purchase of the Ebmpapst W2S130-AA03-77 AC Axial Fan. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
Frequently Asked Questions
What is Ebmpapst W2S130-AA03-77?
Ebmpapst W2S130-AA03-77 is an AC axial fan designed for industrial ventilation and cooling applications.
What type of fan is W2S130-AA03-77?
W2S130-AA03-77 is an AC axial fan with a 130 mm diameter and IP44 protection rating.
What voltage does W2S130-AA03-77 use?
The W2S130-AA03-77 operates on a rated voltage of 230 VAC.
What is the power input of W2S130-AA03-77?
Power input is specified as 190 W at 50 Hz and 205 W at 60 Hz.
What is the speed of W2S130-AA03-77?
The fan speed is rated at 2600 RPM at 50 Hz and 3000 RPM at 60 Hz.
What airflow does W2S130-AA03-77 provide?
Airflow is rated at 350 CFM at 50 Hz and 410 CFM at 60 Hz.
What is the protection rating of W2S130-AA03-77?
W2S130-AA03-77 carries an IP44 protection rating.
What applications can W2S130-AA03-77 be considered for?
The fan can be considered for industrial equipment cooling, electrical cabinet ventilation, HVAC systems, and industrial machinery ventilation.
What should be checked before ordering W2S130-AA03-77?
Before ordering, the complete catalog number, mounting dimensions, power supply voltage, frequency, and airflow requirements should be verified against the existing system specifications.
What should be verified before using W2S130-AA03-77 in an existing system?
Electrical requirements including voltage and frequency, physical dimensions, mounting, and airflow performance should be checked against the existing installation.
