Low-Inertia Servo Design
The MPL-B430P-MJ24AA belongs to the Kinetix MPL family of low-inertia permanent magnet rotary servo motors for industrial motion-control applications.
Allen-Bradley MPL-B430P-MJ24AA Servo Motor 460V 5000RPM 115mm Frame
Available in stock (400)
Regular price
$1,576.81
Sale price
Regular price
Shipping calculated at checkout.
Technical Specifications
| Brand | Allen-Bradley |
| Model Number | MPL-B430P-MJ24AA |
| Product Category | Servo Motor |
| Product Family | Kinetix MPL Low-Inertia Servo Motors |
| Motor Type | Low-Inertia Permanent Magnet Rotary Servo Motor |
| Voltage Class | 460 V AC |
| Frame Size | 115 mm |
| Magnet Stack Length | 76.2 mm (3.0 in.) |
| Rated Speed | 5000 RPM |
| Feedback | Multi-turn High-resolution Encoder |
| Shaft | Keyed Shaft, No Shaft Seal |
| Connector | Circular Bayonet, Facing Shaft |
| Brake | 24 V DC Holding Brake |
| Mounting | IEC Metric, Free Mounting Holes Type FF |
Key Features
5000 RPM Rated Speed
This motor configuration combines a 460 V voltage class with a rated speed of 5000 RPM for applicable servo motion systems.
115 mm Frame
The motor uses a 115 mm frame with a 76.2 mm magnet stack length, defining the mechanical size of this catalog configuration.
Multi-Turn Encoder
A multi-turn high-resolution encoder provides feedback for closed-loop positioning and motion-control applications.
24 V DC Holding Brake
The MJ24AA configuration includes a 24 V DC holding brake for applications where the motor shaft must be held when required by the machine design.
Bayonet Connector
The motor uses a circular bayonet connector facing the shaft together with a keyed shaft extension and IEC metric mounting.
Applications
- Industrial motion-control systems
- Packaging machinery
- Material handling equipment
- Automated assembly systems
- Converting machinery
- Precision positioning equipment
- Production line automation
- Low-inertia servo applications
Purchase Information
We support online purchase of the Allen-Bradley MPL-B430P-MJ24AA Servo Motor. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
Frequently Asked Questions
What is the Allen-Bradley MPL-B430P-MJ24AA?
It is a Kinetix MPL low-inertia permanent magnet rotary servo motor for industrial motion-control applications.
What is the voltage class of MPL-B430P-MJ24AA?
This motor is specified in the 460 V AC voltage class.
What is the rated speed?
The MPL-B430P-MJ24AA is specified for a rated speed of 5000 RPM.
What is the frame size?
The motor uses a 115 mm frame with a 76.2 mm (3.0 in.) magnet stack length.
What feedback device does this motor use?
It uses a multi-turn high-resolution encoder for servo feedback.
Does MPL-B430P-MJ24AA include a brake?
Yes. This configuration includes a 24 V DC holding brake.
What shaft configuration is used?
The motor has a keyed shaft extension without a shaft seal.
What connector configuration does it use?
The MPL-B430P-MJ24AA uses a circular bayonet connector facing the shaft.
Can MPL-B430P-MJ24AA replace another servo motor?
It can be considered after the complete model number and technical requirements have been checked, including voltage, speed, frame size, feedback, brake, shaft and connector configuration.
What should be checked before ordering?
Electrical, mechanical and installation requirements should be checked before ordering, including the servo drive, voltage class, feedback type, brake, mounting, shaft and connector requirements.
