Lever-Type Operation
The 802T-H uses lever-type mechanical actuation with spring return for position and travel detection applications.
Allen-Bradley 802T-H Limit Switch Lever Type 2-Circuit NEMA 4/13
Available in stock (400)
Regular price
$174.39
Sale price
Regular price
Shipping calculated at checkout.
Technical Specifications
| Brand | Allen-Bradley |
| Model Number | 802T-H |
| Product Category | Limit Switch |
| Type | Oiltight Limit Switch |
| Construction | NEMA Type 4 and 13 Oiltight |
| Switch Components | Complete Switch |
| Actuation Type | Lever Type, Spring Return, High Operating Torque |
| Number of Circuits | 2-Circuit |
| Mode of Operation | CW and CCW |
| Action | Snap Acting, Standard Contacts |
| Actuator | Rotary Lever Arm |
| Travel to Operate Contacts | 9° Nominal |
| Torque to Operate Contacts | 0.56 N-m (5 lb-in) Maximum |
| Travel to Reset Contacts | 3.5° Maximum |
| Maximum Travel | 90° |
| Operating Lever | Operating Lever Not Selected |
Key Features
2-Circuit Configuration
The complete switch is configured with two circuits for applicable industrial machine control systems.
High Operating Torque
The operating head is configured for high operating torque, with a documented maximum contact operating torque of 0.56 N-m (5 lb-in).
CW and CCW Actuation
The operating mechanism supports both clockwise and counterclockwise actuation.
90 Degree Maximum Travel
The documented maximum actuator travel is 90 degrees, with nominal contact operation at 9 degrees.
NEMA Type 4 and 13
The 802T-H is specified with NEMA Type 4 and 13 oiltight construction for applicable industrial environments.
Applications
- Machine position detection
- Mechanical end-of-travel detection
- Conveyor control systems
- Material handling equipment
- Industrial machinery control
- Production equipment monitoring
- Factory automation systems
- Mechanical motion detection
Purchase Information
We support online purchase of the Allen-Bradley 802T-H Limit Switch. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
Frequently Asked Questions
What is Allen-Bradley 802T-H?
The 802T-H is an oiltight limit switch with lever-type spring-return actuation, two circuits and clockwise or counterclockwise operation.
Is 802T-H a complete limit switch?
The 802T-H is configured as a complete limit switch for applicable mechanical position and travel detection applications.
How many circuits does 802T-H have?
The documented configuration uses two circuits.
What type of actuator does 802T-H use?
The switch uses a rotary lever-arm operating mechanism with spring return.
Can 802T-H operate in both directions?
Yes. The documented operating mode supports both clockwise and counterclockwise actuation.
What is the maximum travel of 802T-H?
The documented maximum actuator travel is 90 degrees.
How much travel is required to operate the contacts?
The nominal travel to operate the contacts is 9 degrees.
What is the maximum operating torque?
The documented maximum torque to operate the contacts is 0.56 N-m (5 lb-in).
What type of contact action does 802T-H use?
The switch uses snap-acting standard contacts.
What enclosure construction is associated with 802T-H?
The switch is specified with NEMA Type 4 and 13 oiltight construction.
Does 802T-H include a selected operating lever?
The operating lever should be selected according to the mechanical requirements of the intended installation.
What should be checked before ordering 802T-H?
Check the complete catalog number, 2-circuit requirement, lever configuration, CW and CCW operation, operating torque, enclosure requirements and the operating lever required for the intended application.
