4PDT Contact Configuration
The 700-HC24Z24 provides four changeover contacts in a 4PDT configuration for multi-circuit switching in industrial control applications.
Allen-Bradley 700-HC24Z24 General Purpose Relay 4PDT 7A 24V DC
Available in stock (400)
Regular price
$74.88
Sale price
Regular price
Shipping calculated at checkout.
Technical Specifications
| Brand | Allen-Bradley |
| Model Number | 700-HC24Z24 |
| Product Category | General Purpose Relay |
| Series | 700-HC |
| Relay Style | Square Ice Cube Relay |
| Terminal Type | Blade Terminal |
| Contact Configuration | 4PDT |
| Changeover Contacts | 4 |
| Nominal Current | 7 A |
| Coil Voltage | 24 V DC |
| Actuating Voltage Type | DC |
| Low Energy Rating | 10 V, 10 mA |
| Electrical Connection | Plug-In Connection |
| Contact Material | AgNi |
| Electrical Life | Minimum 100,000 Operations |
| Mechanical Life | 50,000,000 Operations, DC |
| Degree of Protection | IP20 with Guarded Terminal Socket |
| Width | 27.7 mm |
| Height | 37.2 mm |
| Depth | 20.7 mm |
Key Features
24V DC Coil
The documented rated control supply voltage is 24 V DC for DC-operated control circuits.
7A Nominal Current
The relay has a documented nominal current rating of 7 A for applicable switching circuits.
Low Energy Contact Rating
The documented low-energy contact rating is 10 V at 10 mA, supporting applicable low-level control signal switching.
Plug-In Blade Connection
The square relay uses blade terminals and a plug-in electrical connection for installation with an appropriate relay socket.
AgNi Contacts
The documented contact material is silver-nickel, identified as AgNi, for the 700-HC24Z24 configuration.
Applications
- Industrial control panels
- Machine automation circuits
- Interposing relay applications
- Multi-circuit control switching
- PLC interface circuits
- Production equipment controls
- Control cabinet assemblies
- General industrial switching circuits
Purchase Information
We support online purchase of the Allen-Bradley 700-HC24Z24 General Purpose Relay. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
Frequently Asked Questions
What is Allen-Bradley 700-HC24Z24?
The 700-HC24Z24 is a Bulletin 700-HC general purpose square relay with blade terminals, a 4PDT contact configuration and a 24 V DC coil.
What contact configuration does 700-HC24Z24 use?
The relay provides four changeover contacts in a 4PDT configuration.
What is the coil voltage of 700-HC24Z24?
The documented rated control supply voltage is 24 V DC.
What is the nominal current rating?
Rockwell Automation lists a nominal current of 7 A for this catalog number.
What is the low-energy rating?
The documented low-energy contact rating is 10 V at 10 mA.
What type of electrical connection does 700-HC24Z24 use?
The relay uses a plug-in connection with blade terminals.
What contact material is used?
The documented contact material is AgNi silver-nickel.
What is the documented electrical life?
The product data specifies a minimum electrical life of 100,000 operations.
What is the documented mechanical life?
Rockwell Automation lists 50,000,000 mechanical operations for DC operation.
What are the dimensions of 700-HC24Z24?
The documented relay dimensions are 27.7 mm wide, 37.2 mm high and 20.7 mm deep.
Can 700-HC24Z24 be considered for an existing relay installation?
It can be considered after the complete catalog number, 24 V DC coil, 4PDT contact arrangement, 7 A current requirement, blade-terminal configuration and socket requirements have been checked.
What should be checked before ordering 700-HC24Z24?
Check the complete model number, 24 V DC control voltage, 4PDT contact arrangement, 7 A nominal current, low-energy switching requirements and the required plug-in socket against the intended control circuit.
