16 AC Input Channels
The 5069-IA16 provides 16 digital AC input channels for detecting state changes from compatible industrial field devices.
Allen-Bradley 5069-IA16 Input Module 16-Point 120/240V AC
Available in stock (400)
Regular price
$269.46
Sale price
Regular price
Shipping calculated at checkout.
Technical Specifications
| Brand | Allen-Bradley |
| Model Number | 5069-IA16 |
| Product Category | Input Module |
| Series | Compact 5000 |
| Product Type | AC Digital Input Module |
| Number of Inputs | 16 |
| Voltage Category | 120/240 V AC |
| Input Signal Range | 79–265 V AC |
| IEC Input Compatibility | Type 1 |
| On-State Voltage, Minimum | 79 V AC |
| SA Power | 240 mA at 79–264 V AC |
| SA Power Passthrough | 9.975 A at 79–264 V AC |
| Power Dissipation | 3.5 W Maximum |
| Thermal Dissipation | 11.9 BTU/hr Maximum |
| Isolation Voltage | 250 V Continuous, Basic Insulation Type |
| Channel Isolation | No Isolation Between Individual Channels |
| Status Indicators | 1 Green/Red Module Status; 16 Yellow/Red I/O Status |
| Input Wiring | Shared Common |
| Dimensions | 138 mm Height × 105 mm Depth |
| Required Terminal Kit | 5069-RTB18-SCREW or 5069-RTB18-SPRING |
Key Features
120/240V AC Signals
The module supports both 120 V AC and 240 V AC signal applications, with a documented input signal range of 79 to 265 V AC.
Shared Common Wiring
The sixteen inputs use a shared common, with input return provided through internal module circuitry to the SA power connection.
Channel Status Indication
Sixteen yellow/red I/O status indicators provide individual input status information together with a green/red module status indicator.
Compact 5000 Platform
The 5069-IA16 is an AC standard input module within the Compact 5000 I/O family for supported industrial control architectures.
Removable Terminal Blocks
The module uses either the 5069-RTB18-SCREW or 5069-RTB18-SPRING terminal kit for field wiring termination.
Applications
- 120 V AC field signal monitoring
- 240 V AC field signal monitoring
- Industrial switch input circuits
- Machine status detection
- Industrial control panels
- Factory automation equipment
- PLC-based machine control
- Compact 5000 I/O systems
Purchase Information
We support online purchase of the Allen-Bradley 5069-IA16 Input Module. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
Frequently Asked Questions
What is Allen-Bradley 5069-IA16?
The 5069-IA16 is a Compact 5000 digital 16-point AC input module designed to detect state transitions from compatible 120 V AC and 240 V AC field signals.
How many input channels does 5069-IA16 provide?
The module provides 16 AC digital input channels.
Does 5069-IA16 support both 120 V AC and 240 V AC?
Yes. Rockwell Automation specifies the module for both 120 V AC and 240 V AC signals.
What is the input signal range of 5069-IA16?
The documented input signal range is 79 to 265 V AC.
What IEC input type does 5069-IA16 support?
The module is specified for IEC Type 1 input compatibility.
What SA power does 5069-IA16 use?
The module uses AC SA power, with a documented rating of 240 mA at 79 to 264 V AC.
Are the individual input channels isolated from each other?
No isolation is specified between individual channels.
Do the inputs use a shared common?
Yes. The 5069-IA16 inputs use a shared common with return through internal module circuitry to the SA power connection.
What status indicators are provided?
The module provides one green/red module status indicator and 16 yellow/red I/O status indicators.
Which terminal blocks are used with 5069-IA16?
The module requires either the 5069-RTB18-SCREW or 5069-RTB18-SPRING terminal kit.
Is 5069-IA16 a DC input module?
No. The 5069-IA16 is the AC standard input model in the Compact 5000 digital I/O family and supports 120/240 V AC signals.
What should be checked before ordering 5069-IA16?
Check the complete catalog number, 16-channel requirement, AC signal voltage, shared-common wiring, SA power arrangement, terminal block type and Compact 5000 system configuration.
