Allen-Bradley 2711P-T10C22D9P HMI 10.4-inch 800x600 24VDC

Allen-Bradley 2711P-T10C22D9P HMI 10.4-inch 800x600 24VDC

Fast Quote
Global Shipping
Bulk Order Support

Available in stock (200)

$2,072.66

Shipping calculated at checkout.

Request a Quote

In Stock
Free Returns And Exchanges Within 30 days
Bulk purchases are eligible for price discounts.

Brand	Allen-Bradley
Model Number	2711P-T10C22D9P
Product Category	HMI
Product Family	PanelView Plus 7 Performance
Terminal Type	Touch Screen Terminal
Display Type	TFT Color
Display Size	10.4 in.
Display Resolution	800 × 600 SVGA
Operator Input	Touch
Communication	Dual Ethernet
Input Voltage	24 VDC
Input Voltage Range	18-30 VDC
RAM	1 GB
Storage	512 MB
USB Host Ports	2
USB Device Port	1

Key Features

10.4-inch TFT Display

The 2711P-T10C22D9P uses a 10.4-inch TFT color display for machine visualization and operator interface applications.

800 × 600 SVGA

The documented display resolution is 800 × 600 SVGA for graphical machine and process information.

Touch Screen Input

The PanelView Plus 7 Performance terminal provides touch screen operator input.

Dual Ethernet

The documented communication configuration includes dual Ethernet ports for supported industrial network functions.

1 GB RAM

The terminal configuration provides 1 GB RAM with 512 MB of storage.

24VDC Power

The terminal uses 24 VDC nominal power with a documented input voltage range of 18-30 VDC.

Applications

Industrial machine operator interfaces
PLC system visualization
Machine status monitoring
Production equipment control panels
Industrial process visualization
Operator data entry interfaces
Automation system monitoring
Machine control and maintenance panels

Purchase Information

We support online purchase of the Allen-Bradley 2711P-T10C22D9P HMI. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.

Frequently Asked Questions

What is Allen-Bradley 2711P-T10C22D9P?
Allen-Bradley 2711P-T10C22D9P is a PanelView Plus 7 Performance HMI terminal with a 10.4-inch TFT color touch display and dual Ethernet communication.

What is the display size of 2711P-T10C22D9P?
The documented display size is 10.4 inches.

What is the display resolution of 2711P-T10C22D9P?
The documented display resolution is 800 × 600 SVGA.

What operator input does 2711P-T10C22D9P use?
The terminal provides touch screen operator input.

What power supply does 2711P-T10C22D9P use?
The terminal uses 24 VDC nominal power with a documented input range of 18-30 VDC.

Does 2711P-T10C22D9P provide Ethernet communication?
Yes. The documented configuration includes dual Ethernet ports.

How much RAM does 2711P-T10C22D9P provide?
The terminal is specified with 1 GB RAM.

What storage capacity does 2711P-T10C22D9P provide?
The documented storage capacity is 512 MB.

Does 2711P-T10C22D9P provide USB connectivity?
Yes. The documented configuration includes two USB host ports and one USB device port.

What is the operating temperature range of 2711P-T10C22D9P?
The documented operating temperature range is 0°C to 55°C.

What should be checked before ordering 2711P-T10C22D9P?
Check the complete catalog number, 10.4-inch display requirement, 24 VDC power requirements, Ethernet interfaces, mounting requirements and application requirements before ordering.

What should be verified before using 2711P-T10C22D9P in an existing system?
Electrical, communication, mechanical, software and installation requirements should be checked against the existing system documentation before use.
