PanelView Plus Display Module
The 2711P-RDT10C is a separate PanelView Plus display module identified by Rockwell Automation as a 1000 touch color display.
Allen-Bradley 2711P-RDT10C PanelView Plus HMI Display Module 10.4in TFT
Available in stock (400)
Regular price
$714.53
Sale price
Regular price
Shipping calculated at checkout.
Technical Specifications
| Brand | Allen-Bradley |
| Model Number | 2711P-RDT10C |
| Product Category | HMI Display Module |
| Product Family | PanelView Plus |
| Display Module | 1000 Touch Color Display |
| Display Size | 10.4 in |
| Display Type | Color Active-Matrix TFT LCD |
| Resolution | 640 x 480 Pixels |
| Operator Input | Touch Screen |
| Touch Screen Type | Analog Resistive |
| Luminance | 300 cd/m² |
| Display Area | 211 x 158 mm |
| Backlight | CCFL, 50,000 hr Minimum Life |
| Degree of Protection | IP54 / IP65 |
| Cutout Dimensions | 224 x 305 mm |
| Dimensions | 329 x 248 x 55 mm |
| Approximate Weight | 2.6 kg |
| UPC | 611320817102 |
Key Features
10.4-Inch Color TFT
The module uses a 10.4-inch color active-matrix TFT LCD for graphical operator-interface applications.
Touch-Screen Operation
An analog resistive touch screen provides the operator-input interface without an integrated keypad.
640 x 480 Resolution
The display provides a documented resolution of 640 x 480 pixels with a visible display area of 211 x 158 mm.
300 cd/m² Luminance
The documented display luminance is 300 cd/m² for the 10.4-inch color TFT display.
Panel-Mount Display Assembly
The documented panel cutout is 224 x 305 mm, with overall dimensions of approximately 329 x 248 x 55 mm.
Applications
- PanelView Plus operator-interface systems
- Industrial machine visualization
- Production line operator panels
- Process monitoring interfaces
- Machine status and control displays
- Manufacturing equipment HMIs
- Industrial control panel displays
- PanelView Plus display-module service applications
Purchase Information
We support online purchase of the Allen-Bradley 2711P-RDT10C HMI Display Module. If you need to make bulk purchases and inquire about other products, please contact our team to inform us of your purchase requirements. We will provide you with information such as quantity quotations, delivery dates, and transportation methods.
Frequently Asked Questions
What is Allen-Bradley 2711P-RDT10C?
It is a PanelView Plus display module described by Rockwell Automation as a 1000 touch color display.
Is 2711P-RDT10C a complete HMI terminal?
The catalog number identifies a display module rather than a complete configured PanelView Plus terminal.
What is the display size?
The 2711P-RDT10C uses a 10.4-inch TFT color display.
What is the display resolution?
The documented resolution is 640 x 480 pixels.
What type of operator input does it use?
The module uses touch-screen operator input with an analog resistive touch interface.
What is the display luminance?
The documented luminance is 300 cd/m².
What is the visible display area?
The documented display area is 211 x 158 mm.
What are the panel cutout dimensions?
The documented cutout dimensions are 224 x 305 mm.
What are the overall dimensions?
The documented dimensions are approximately 329 mm wide, 248 mm high and 55 mm deep.
What is the approximate weight?
The documented approximate weight is 2.6 kg.
Can 2711P-RDT10C replace another PanelView display module?
It can be considered after the complete model number and technical requirements have been checked. Display size, operator-input type, series, backlight technology, firmware and installation requirements should be verified against existing system requirements.
What should be checked before ordering?
The complete catalog number, display-module series, 10.4-inch display requirement, touch input, panel dimensions, associated logic module and firmware requirements should be checked before ordering.
